东芝最新的工业控制器uniifed nv系列控制器，是超越现有的一大步V系列应用于世界各地的工业的功能包括高速逻辑，测序，电机速度控制，连续控制。高速I/O通信使用了业界第一款100Mbps容错环网“TC-net I/O”，连接远程，现场安装I/O。

功能细节

高速处理比特和整数处理:20ns;浮点数加/乘:120 ns

控制周期短3个单独定时任务:0.5 ms ~ 1000ms

程序容量大程序可达256千步(指令)，可达385个周期程序

高数据容量局部/全局变量256 K字;I/O变量16384个16位字

中断总共16个中断任务

多控制器每机箱最多3个控制器;多达4个通信模块;冗余

控制器和网络配置可能

4种IEC 61131-3标准语言:LD、FBD、SFC和ST

内存可靠性每个模块内部内存中的纠错ECC电路

这个强大的控制器的主要特点是:

•容错环100mbps I/O通信

•直接执行IEC标准，提高速度

ASIC硬件中的控制语言

•采用冗余模块，可靠性更高

错误检查和纠正ECC内存

•千兆监控网络
