该网关提供了一种将智能电网兼容IED与施耐德电气Unity系列集成的有效方法，包括Quantum、Premium和M340可编程自动化控制器，以及任何其他Modbus TCP/IP设备。Modbus TCP/IP至IEC 61850网关支持常见的IEC 61850应用，包括变电站自动化、甩负荷和高级SCADA数据采集。

该网关使Modbus TCP/IP网络上的SCADA控制系统能够在过程级(如继电器和开关设备)、间隔级(如保护设备)和变电站自动化级(如PLC/PACs和SCADA控制系统)从多达45个IEC 61850 IED收集、监测、趋势分析和控制粒度实时数据。高级集成、配置和诊断网关提供的配置实用程序使用IED配置文件(cid)来导入复杂的IEC 61850数据结构，然后将IEC 61850 IED标签映射到Modbus TCP/IP寄存器。映射的IED标签结构可以直接导出到Unity Pro，用于Quantum、Premium和M340项目。状态改变时，由IED提供的GOOSE、报告控制块和MMS读取消息被写入Modbus TCP/IP服务器。

网关的时间通过定期更新请求与协调世界时(UTC系统)同步。gateway与Unity Pro系列紧密集成，提供自动生成的特定应用变量和功能块文件。IED拖放IEC 61850数据属性允许简单的Modbus映射，并且配置可以存储在为灾难恢复网关提供的工业SD卡中。关于IEC 61850
C 61850是变电站自动化系统的新国际标准，因为它具有监测和控制IED设备的先进能力，并且它定义了智能电网应用的主干通信。智能电网是指由互联设备和技术组成的网络，它构成了一个高效的现代电力网络。IEC 61850标准创建了一个真正可互操作的智能设备网络，为公用事业提供商提供前所未有的数据可用性，并允许更好地分配和分配能源。施耐德电气在提供能源应用现代化解决方案方面的优势和主动性得到了新的Modbus TCP/IP到IEC 61850网关的补充和进一步扩展

CLS216 温度控制器现场自动设置应用全

The gateway provides an efficient way to integrate smart grid compatible IEDs with Schneider Electric's Unity family, including Quantum, Premium and M340 programmable automation controllers, as well as any other Modbus TCP/IP device. The Modbus TCP/IP to IEC 61850 gateway supports common IEC 61850 applications, including substation automation, load shedding, and advanced SCADA data acquisition.

The gateway enables SCADA control systems over Modbus TCP/IP networks to operate from up to 45 IEC 61850 at the process level (such as relays and switchgear), at the interval level (such as protection equipment) and at the substation automation level (such as PLC/PACs and SCADA control systems) IED collects, monitors, trends, and controls granular real-time data. The configuration utility provided by the Advanced Integration, Configuration, and Diagnostics Gateway uses IED configuration files (cid) to import complex IEC 61850 data structures and then maps IEC 61850 IED tags to Modbus TCP/IP registers. Mapped IED tag structures can be exported directly to Unity Pro for Quantum, Premium, and M340 projects. When the status changes, GOOSE, report control block, and MMS read messages provided by IED are written to the Modbus TCP/IP server.

The time of the gateway is synchronized with the Coordinated Universal Time (UTC system) through periodic update requests. gateway is tightly integrated with the Unity Pro family, providing automatically generated application-specific variables and feature block files. IED Drag-and-drop IEC 61850 data attributes allow for simple Modbus mapping, and the configuration can be stored on the industrial SD card provided for the disaster recovery gateway. About IEC 61850
C 61850 is the new international standard for substation automation systems because it has advanced capabilities to monitor and control IED devices, and it defines backbone communications for smart grid applications. A smart grid is a network of interconnected devices and technologies that make up an efficient modern electricity network. The IEC 61850 standard creates a truly interoperable network of smart devices, providing utility providers with unprecedented data availability and allowing for better distribution and distribution of energy. Schneider Electric's strengths and initiative in providing modern solutions for energy applications are complemented and further extended by the new Modbus TCP/IP to IEC 61850 gateway
