CC-PAOH01 数字输入输出模块 通信冗余系统

CC-PAOH01 数字输入输出模块 通信冗余系统

C300控制器模块

运行 CEE (控制操作系统)支持 PMIO

C系列 1/0

A系列卡件式 1/0

灵活的 1/0 支持:

可混合使用不同的 1/0 接口支持2个IOLINK 接口

每个C300 最多支持 64个冗余 1/0 模件

每个 1OL 可以支持 40 冗余模件

C300控制器I/O链路组态

两条链路支持最多 64块 //O模块

每条 1/0链路用不同的色标区分方便维护

IOTA上的I/O链路地址通过一个预制好的跳线插入来确定地址

C300控制器的可用性 Hone

C300所有的RAM内存具有ECC功能(Error Correction Checking)

C300 Flash内存经过校验和(check-summed)带有启动诊断与运行诊断程序

由于使用集成度的电路，部件，所以具有的 MTTF(平均到故障时间) C300 冗余的通道错误插入测试

CC-PAOH01 数字输入输出模块 通信冗余系统

C300 controller module

Running CEE (Control Operating System) supports PMIO

C Series 1/0

A series card type 1/0

Flexible 1/0 support:

Different 1/0 interfaces can be mixed. Two IOLINK interfaces are supported

Each C300 supports up to 64 redundant 1/0 modules

Each 1OL can support 40 redundant modules

C300 Controller I/O link configuration

Two links support a maximum of 64 //O modules

Each 1/0 link is distinguished by a different color code for easy maintenance

The I/O link address on IOTA is determined by inserting a pre-made jumper

Availability of C300 controller Hone

Error Correction Checking (ECC) function for all RAM memory in C300

The C300 Flash memory is checksummed with the startup diagnostics and the running diagnostics

Due to the use of integrated circuits, components, so has the MTTF(mean time to failure) redundant C300 channel error insertion test
