系统组件及其用途列出标准产品和他们的型号，以及每种标准产品的规格在Tricon系列中有关完整信息，请参阅Tricon规划和安装指南。Tricon概述组件底盘主底盘室主处理器、内存备份电池、通信模块和输入/输出模块。扩展机箱，用于其他高达100英尺（30英尺）的输入/输出模块米）远离干管底盘。

在受限应用中，高达1000英尺（300英尺）的操作仪表）支持。用于输入/输出模块的RXM机箱距离7.5英里（12公里）从主机箱。机械键控每个插槽Tricon通过机械键连接到与特定类型的单元这可以防止将模块安装到插槽不正确。

用于机箱安装和外壳规格，见第25页。电源模块的模块提供逻辑电源主、扩展或RXM底盘。提供24 VDC、115VAC和230 VAC版本。这个每个电源的额定功率为140°F（60°C）时为175瓦。主处理器主处理器执行系统诊断和用户写入控制程序。通信模块Tricon通信模块（TCM）支持多个Triconex协议和应用和用户编写的应用程序以太网（802.3）网络，包括TriStation、Modbus TCP和OPC。

Enterasys A2H124-24FX 交换机卡件

System Components and their uses List standard products and their models, as well as specifications for each standard product in the Tricon family for complete information, see the Tricon Planning and Installation Guide. Tricon Overview Component chassis Main chassis room Main processor, memory backup battery, communication module and input/output module. Expansion chassis, used for other input/output modules up to 100 feet (30 feet) in meters) away from the trunk chassis.

In restricted applications, operating instruments up to 1000 feet (300 feet) are supported. The RXM chassis for input/output modules is 7.5 miles (12 km) from the main chassis. Mechanical keying Each slot Tricon is connected to a specific type of unit via mechanical keys This prevents the module from being installed into the slot incorrectly.

For case mounting and housing specifications, see page 25. Power module The module provides the main, expansion, or RXM chassis for logical power supplies. Available in 24 VDC, 115VAC, and 230 VAC versions. This is rated at 175 watts per supply at 140°F (60°C). Main processor The main processor performs system diagnostics and user write control programs. The Tricon Communications Module (TCM) supports multiple Triconex protocols and applications and user-written application Ethernet (802.3) networks, including TriStation, Modbus TCP, and OPC.
