DEIF IOM230 调速 调压模拟量模块

DEIF IOM230 调速 调压模拟量模块

DEIF IOM230 调速 调压模拟量模块

1、左上角有一电源指示灯，绿色表示正常

2、左下部有一电源指示灯，绿色表示IOM230与控制器CANC通信正常。

IOM230的6，4两端或AGC242的15，13两端跨接120欧电阻。

3、用+/-25m A的调速/调压输出，这样做的目的:电流信号抗干扰强及损耗小。

4、在调速输出7，8两端并联150欧电阻，推荐此电阻最好并在....

DEIF IOM230 调速 调压模拟量模块

1, there is a power indicator in the upper left corner, green indicates normal

2. There is a power indicator on the lower left. The green indicator indicates that the IOM230 communicates with the controller CANC properly.

The 6,4 ends of the IOM230 or the 15,13 ends of the AGC242 are cross-connected to a 120 ohm resistor.

3, with +/ -25mA speed regulation/voltage regulation output, the purpose of doing so: strong anti-interference current signal and small loss.

4, Parallel 150ohm resistance at both ends of the speed control output 7 and 8, it is recommended that this resistance is best and at....
