技术实现要素：

本实用新型的目的是克服现有技术的缺陷，提供一种柴油发电机组并机、并网及反并网的控制系统，接线简单，可以实现多个柴油发电机组的并机、并网及反并网的控制。

实现上述目的的技术方案是：一种柴油发电机组并机、并网及反并网的控制系统，包括主电网开关控制器、市电开关、发电机总开关、若干个柴油发电机组和若干个柴油发电机组控制器，其中：

所述若干个柴油发电机组并联设置，每个柴油发电机组均通过一个机组断路器接入并联母线；

所述发电机总开关设置在所述并联母线上；

所述并联母线接入市电，且所述并联母线和市电之间设置有所述市电开关；

所述若干个柴油发电机组控制器与所述若干个柴油发电机组一一对应地设置，每个柴油发电机组控制器与相应的柴油发电机组的机组断路器相连；

所述主电网开关控制器分别与所述市电开关、发电机总开关和若干个柴油发电机组控制器相连。

DEIF AGC-242电流变送器

Technical implementation elements:

The utility model aims to overcome the defects of the prior art, and provides a diesel generator set parallel, grid-connected and anti-grid-connected control system, which has simple wiring and can realize the control of multiple diesel generator sets parallel, grid-connected and anti-grid-connected.

The technical scheme to achieve the above purpose is: a diesel generator set parallel, grid-connected and anti-grid-connected control system, including the main grid switch controller, mains switch, generator main switch, a number of diesel generator sets and a number of diesel generator set controller, wherein:

The diesel generator sets are arranged in parallel, and each diesel generator set is connected to a parallel bus through a unit circuit breaker;

The main switch of the generator is arranged on the parallel bus;

The parallel bus is connected to the mains, and the mains switch is arranged between the parallel bus and the mains;

The diesel generator set controller and the diesel generator set are arranged one by one, and the controller of each diesel generator set is connected with the circuit breaker of the corresponding diesel generator set.

The main power grid switch controller is respectively connected with the mains switch, the main generator switch and a plurality of diesel generator set controllers.
