产品说明

装置采用简化的结构设计。它能够通过以太网和USB连接处理通信。板载文档和系统更新是标准功能，插入式更换细节被实施到单元中,以延长模块的使用寿命。这些装置设计用于在单个网络中连接到超过32个发电机组模块。

对于本地节点,反射内存板显示为共享内存。任何级别的软件(包括应用程序本身)都可以将数据写入内存或从内存中读取数据。写入一个节点的反射内存的数据由网络硬件传输到所有其他节点，并放置在这些节点的反射内存板上的相同地址中。这种数据传输无需任何节点上的处理器参与即可完成。通过该系统，网络上的所有节点都具有可立即访问的共享数据的本地副本。可以通过位于一个板边缘的两个光纤连接器与 AutoMax UDC模块通信。该板还用于监控驱动操作和运行电机控制算法。

其他接口包括PMI接口连接器、AC电源技术电路、仪表端口、Flex I/o、同步传输端口连接器和PMI处理器电路。仪表端口位于沿一个板边缘的端子条内。这些可以使用14-22 AWG 双绞线(最大长度13英尺)连接到外部模拟设备。

MAESTRO 60X714 舵机驱动器 适用于各种过程控制器

Product description

The device adopts simplified structure design. It is capable of handling communications via Ethernet and USB connections. On-board documentation and system updates are standard features, and plug-in replacement details are implemented into the unit to extend the life of the module. These units are designed to connect to more than 32 generator set modules in a single network.

For local nodes, the reflected memory board appears as shared memory. Any level of software, including the application itself, can write data to or read from memory. Data written to the reflected memory of one node is transmitted by the network hardware to all other nodes and placed at the same address on the reflected memory boards of those nodes. This data transfer can be done without the involvement of processors on any node. With this system, all nodes on the network have a local copy of the shared data that is instantly accessible. The AutoMax UDC module can be communicated via two fiber optic connectors located at the edge of one board. The board is also used to monitor drive operation and run motor control algorithms.

Other interfaces include PMI interface connectors, AC power technology circuits, instrument ports, Flex I/o, synchronous transfer port connectors, and PMI processor circuits. The instrument port is located in a terminal strip along the edge of a board. These can be connected to external analog devices using 14-22 AWG twisted pair wire (maximum length 13 feet).
