LAM 605-064676-007 模块

LAM 605-064676-007 模块

LAM 605-064676-007 模块

现场控制是一系列高度模块化的分布式I/O和控制产品。它们很合适适用于各种主机体系结构。现场控制系统的核心是总线接口单元。

总线接口单元提供智能处理、I/O扫描和*多八个I/O组的功能配置模块。总线接口单元及其模块一起构成现场控制站插图。

总线接口单元和I/O模块封装在坚固、紧凑的铝外壳中。单元和I/O模块用螺栓牢固地固定在单独的接线板上，接线板提供所有现场数据接线端子。I/O接线板是通用的，允许使用不同的I/O模块类型安装在同一基座上。

I/O接线板可与箱式端子、屏障式端子一起使用端子或线路板连接器。所有接线板必须安装在DIN导轨上。这个DIN导轨作为接地系统的一个组成部分，也可以安装在面板上。

LAM 605-064676-007 模块

Field Control is a series of highly modular distributed I/O and control products. They are suitable for a variety of host architectures. The core of the field control system is the bus interface unit.

The bus interface unit provides intelligent processing, I/O scanning, and functional configuration modules for up to eight I/O groups. The bus interface unit and its module together constitute the field control station illustration.

The bus interface unit and I/O module are packaged in a robust, compact aluminum housing. The units and I/O modules are bolted securely to separate patch boards that provide all field data terminals. The I/O patch board is universal, allowing different I/O module types to be mounted on the same base.

I/O terminals can be used with box terminals, screen terminals or circuit board connectors. All connectors must be mounted on DIN rails. This DIN rail is an integral part of the grounding system and can also be mounted on the panel.
