下图为C2控制器故障情况下的Experion系统基本拓扑图 容错以太网监控网络。

Experion系统仍然提供相同的配置， 控制和的功能与控制网监控网络一样。然而,以下 指导方针是的容错以太网监控网络。

 l为每个FTE桥接模块分配一个的设备索引。 l同一台Experion服务器不能同时支持控制网、以太网和容错 与不同的C2进程控制器(也称为C2控制器)进行以太网通信。

参数规格

输出数量16(4点/共同)

输出电压范围74-265 VAC, 47-63 Hz

输出电流额定值

CC-PCF901 霍尼韦尔DCS模块

The following is a basic topology of the Experion system with a C2 controller failure, fault-tolerant Ethernet monitoring network.

The Experion system still provides the same configuration, controls and functions as the control network monitoring network. However, the following guidelines are fault-tolerant Ethernet monitoring networks.

l Assign a device index to each FTE bridge module. The same Experion server cannot simultaneously support control network, Ethernet, and fault-tolerant Ethernet communication with different C2 process controllers (also known as C2 controllers).

Parameter specification

Output quantity 16(4 points/common)

Output voltage range 74-265 VAC, 47-63 Hz

Output current rating
