SCXI-1193 NI射频多路复用器开关模块 ​32​通道 高密度

SCXI-1193 NI射频多路复用器开关模块 32通道 高密度

The following topologies are achievable with the SCXI 1193: a Quad 8 x 1 Multiplexer, a Quad 4 x 1 Terminated Multiplexer, a Dual 16 x 1 Multiplexer, a Dual 8 x 1 Terminated Multiplexer, a 32 x 1 Multiplexer, a 16 x 1 Terminated Multiplexer, and an Independent module. This RF Multiplexer Switch Module can be used with several different cables.

These cables include: the MCX-MCX cable, the MCX-BNC cable, the MCX-SMB cable, or the MCX-SMA cable. Each of these cables can be purchased in a 0.3 m or 1.0 m length. There is also a 50 Ohm MCX Terminator available. When the 50 Ohm MCX Terminator is on half of the 32 channels, then the user can utilize the module as a terminated multiplexer.

The device has a DC power requirement of +5 VDC at 50 mA, +18.5 VDC to +25 VDC at 170 mA, and -18.5 VDC to -25 VDC at 170 mA. The NI SCXI-1193 module has 36 MCX jacks for I/O connectors, 2 SMB jacks for trigger connectors, relays made of silver palladium and gold, and a maximum scan rate of 100 operations per second. The device has an electromechanical latching relay type. The NI device weighs 2 oz, and measures 1.2 x 6.8 x 7.8 in. in physical dimensions. It has a recommended operating temperature range of 0 °C to 50 °C, a storage temperature range of -20 °C to 70 °C, and a noncondensing humidity range of 5% to 85%.
