FX3U-4DA-ADP的产品参数

　　1、FX3U-4DA-ADP四路适配器的产品特点:

　　FX3U-4DA-ADP模拟输出适配器（以后称之为FX3U-4DA-ADP）用于将4点模拟输出（电压输出和电流输出）转换成12位的数字值，并将这个值输出到可编程控制器中。

　　2、FX3U-4DA-ADP的接线方法

　　1）四个模拟输出通道可接受的输出为0到10V DC、4到20MA或0到5V DC，（电压输出和电流输出）。

　　2）根据，模拟输出可在电压输出或电流输出中进行选择。此时，假定设置为四通道公用模拟输出。使输出特性与两通道相容。

　　3）模拟到数字的转换特性可以调节。使用FROM/TO指令与PLC进行数据传输。此模块占用8个I/O点，它们可被分配为输入或输出。

　　4）FX3U-4DA-ADP可连接到FX3G、FX3U和FX3UC的可编程控制器。

　　5）三菱PLC与模块FX3U-4DA-ADP的连接：FX3U系列PLC可连接的FX3U-4DA-ADP数目为4或更少。对于每个带有源扩展单元的主单元来说，FX3G系列PLC可连接的FX3U-4DA-ADP数目为4或更少，FX3UC系列PLC可连接的FX3U-4DA-ADP数目为8或更多。

三菱FX3U系列PLC模块FX3U-4DA-ADP可编程控制器

Product parameters of FX3U-4DA-ADP

1, FX3U-4DA-ADP four-way adapter product features:

The FX3U-4DA-ADP analog output adapter (later called FX3U-4DA-ADP) is used to convert the 4-point analog output (voltage output and current output) into a 12-bit digital value and output this value to the programmable controller.

2. Wiring method of FX3U-4DA-ADP

1) The four analog output channels accept outputs from 0 to 10V DC, 4 to 20MA, or 0 to 5V DC (voltage output and current output).

2) According to the analog output can be selected between voltage output or current output. At this point, assume a four-channel common analog output. Make the output characteristics compatible with both channels.

3) The conversion characteristics of analog to digital can be adjusted. Data transfer with PLC using FROM/TO instruction. This module occupies 8 I/O points, which can be assigned as input or output.

4) FX3U-4DA-ADP can be connected to FX3G, FX3U and FX3UC programmable controllers.

5) Mitsubishi PLC and module FX3U-4DA-ADP connection: FX3U series PLC can be connected to the number of FX3U-4DA-ADP 4 or less. For each main unit with a source expansion unit, the FX3G series PLC can connect 4 or fewer FX3U-4DA-ADPs, and the FX3UC series PLC can connect 8 or more FX3U-4DA-ADPs.
