PCD231B101 3BHE025541R0101自动化控制模块请勿从控制柜上拆下印刷电路板（PCB）除非绝对必要。

如果必须从控件中移除PCB机柜，请遵循以下预防措施：除边缘外，请勿触摸PCB的任何部分。请勿触摸电导体、连接器或使用导电器件或用手操作部件。更换PCB时，将新PCB保持在防静电塑料中保护袋，直到你准备好安装它。立即从控制柜中卸下旧PCB后，将其放在防静电保护袋。

为了防止操作引起的对电子部件的损坏，阅读并遵守伍德沃德手册82715，指南中的预防措施电子控制装置、印刷电路板和模块。保护接地（PE）必须连接至设备背面，靠近带有符号的标签（或其他3个标签中的1个类似的没有标签的终端点），以减少电击的风险。

该连接将使用螺纹成形螺钉进行。列车长提供连接必须有一个适当尺寸的环形接线片和更大的导线小于或等于3.0 mm（12 AWG）。

PCD231B101 3BHE025541R0101 发电厂 化工厂模块 用于重工业系统

PCD231B101 3BHE025541R0101 Automation Control Module Do not remove the printed circuit board (PCB) from the control cabinet unless absolutely necessary.

If you must remove the PCB cabinet from the controls, follow the following precautions: Do not touch any part of the PCB other than the edges. Do not touch electrical conductors, connectors, or use conductive devices or handle parts by hand. When replacing a PCB, keep the new PCB in an anti-static plastic protective bag until you are ready to install it. Immediately remove the old PCB from the control cabinet and place it in an anti-static bag.

To prevent damage to electronic components caused by operation, read and follow Woodward Manual 82715, the guide to Preventive Measures for electronic control devices, printed circuit boards and modules. The protective ground (PE) must be connected to the back of the device, near a labeled label (or a similar unlabeled end point on 1 of the other 3 labels) to reduce the risk of electric shock.

The connection will be made using thread forming screws. Conductors providing connections must have an appropriately sized ring patch and larger wires less than or equal to 3.0 mm (12 AWG).
