Trafotek CHK0520线路输出电抗器520 A 500/690伏50HZ

Trafotek CHK0520线路输出电抗器520 A 500/690伏50HZ

产品特点:

该产品为铁芯干式铁芯采用低损耗冷轧硅钢片，经高速冲床冲剪，具有毛刺小、规则均匀、叠片整齐美观，运行低温升低噪音;

◆线圈采用绝缘导线，经机器绕制，具有平整度好，外型美观的优点;

◆铁芯柱经多个气隙分成均匀小块，气隙采用高温度连接胶将芯柱的每个小段与上、下辄紧密的粘接起来;

◆电抗器装配过程中，所有夹件经过防腐蚀处理，关键夹件采用无磁材料，并经预烘-真空浸漆-热烘固化等流程，使滤波电抗器线圈及铁芯牢固成为一体，大大减少了运行时温升及噪声，有效提高了电抗器的品质;

◆滤波电抗器体积小、重量轻、外形美观、接线方便等优点。

Product features:

The product is an iron core dry type iron core with low loss cold rolled silicon steel sheet, punching and cutting by high-speed press, with small burrs, uniform rules, neat and beautiful lamination, running low temperature and low noise;

◆ Coil using insulated wire, machine wound, has the advantages of good flatness, beautiful appearance;

◆ The core column is divided into uniform small pieces through a number of air gaps. The air gap uses high temperature connecting glue to connect each small section of the core column tightly with the upper and lower parts;

◆ Reactor assembly process, all clips through anti-corrosion treatment, the key clips are made of non-magnetic materials, and through the process of pre-drying - vacuum paint - hot drying curing, so that the filter reactor coil and iron core firmly into one, greatly reducing the temperature rise and noise during operation, effectively improve the quality of the reactor;

◆ Filter reactor small size, light weight, beautiful appearance, easy wiring and other advantages.
