PDM5.1 主要功能

电源供电： 为连接的设备提供稳定的电源，确保设备的正常运行。

信号隔离： 通过光耦合器或其他隔离技术，实现信号的电气隔离，提高系统的可靠性。

通信接口： 提供多种通信接口，如RS485、CANbus、以太网等，用于与其他设备进行通信。

协议支持： 支持多种通信协议，如Modbus、IEC 60870-5-104等，实现与不同厂商设备的互联。

数据采集： 采集本地设备的运行数据，如电压、电流、温度等。

远程控制： 实现对本地设备的远程控制和配置。

PDM5.1 结构组成

电源模块： 为整个模块提供电源，包括交流输入、整流、滤波、稳压等电路。

信号处理模块： 对采集到的模拟信号进行放大、滤波、A/D转换等处理。

通信模块： 实现与其他设备的通信，包括物理层、数据链路层、网络层等。

微处理器： 控制整个模块的运行，实现数据采集、处理、通信等功能。

PDM5.1 应用场景

变电站自动化： 用于采集变电站设备的运行数据，实现对变电站的远程监控和控制。

配电自动化： 用于实现配电网的自动化控制，提高供电可靠性。

电力调度： 用于采集电网的运行数据，为电力调度提供支持。

电力监控： 用于实现对电力系统的实时监控，及时发现故障。

PDM5.1 的优势

模块化设计： 方便安装和维护。

高可靠性： 采用冗余设计和工业级组件，提高系统的可靠性。

灵活性： 支持多种通信协议和接口，适应不同的应用环境。

易于扩展： 可以根据需要增加功能模块。

PDM5.1 电源和分布式通信模块

PDM5.1 Main functions

Power supply: Provides stable power supply for connected devices to ensure normal operation of the devices.

Signal isolation: Electrical isolation of signals is achieved through optical couplers or other isolation technologies to improve the reliability of the system.

Communication interface: Provides a variety of communication interfaces, such as RS485, CANbus, Ethernet, etc., for communication with other devices.

Protocol support: Supports a variety of communication protocols, such as Modbus, IEC 60870-5-104, etc., to achieve the interconnection with devices from different manufacturers.

Data collection: Collects the operating data of the local device, such as voltage, current, and temperature.

Remote control: Remote control and configuration of local devices.

PDM5.1 structure composition

Power module: Provides power for the entire module, including AC input, rectification, filtering, voltage regulation and other circuits.

Signal processing module: The collected analog signal is amplified, filtered, A/D conversion and other processing.

Communication module: implements communication with other devices, including the physical layer, data link layer, and network layer.

Microprocessor: Control the operation of the entire module to achieve data acquisition, processing, communication and other functions.

PDM5.1 Application scenarios

Substation automation: used to collect the operation data of substation equipment to achieve remote monitoring and control of the substation.

Distribution automation: It is used to realize the automatic control of the distribution network and improve the reliability of power supply.

Power dispatching: Used to collect the operation data of the power grid to provide support for power dispatching.

Power monitoring: It is used to realize real-time monitoring of the power system and timely detection of faults.

Advantages of PDM5.1

Modular design: easy installation and maintenance.

High reliability: Redundant design and industrial-grade components improve system reliability.

Flexibility: Supports a variety of communication protocols and interfaces to adapt to different application environments.

Easy to expand: Functional modules can be added as needed.
