CPUX01-01 嵌入式控制单板计算机

CPUX01-01 嵌入式控制单板计算机

概述

CPUX01-01 是一款嵌入式控制单板计算机，基于 NXP i.MX 8M Plus 处理器开发。它具有强大的处理能力、丰富的功能和小型紧凑的尺寸，适用于各种工业控制、物联网和边缘计算应用。

主要功能

强大的处理能力： 基于 NXP i.MX 8M Plus 处理器，主频高达 1.5千兆赫，采用四核 ARM Cortex-A53 架构，可提供强大的处理能力，满足各种复杂应用需求。

丰富的功能： 支持多种接口和通信协议，包括： 以太网：千兆以太网接口，支持 TCP/IP 协议栈。

USB：2 个 USB 3.0 接口，支持高速数据传输。

串口：2 个 RS-232/485 接口，支持串口通信。

CAN 总线：1 个 CAN 总线接口，支持 CAN 总线通信。

GPIO：大量 GPIO 引脚，可扩展各种外设功能。

小型紧凑的尺寸： 尺寸为 90 x 60 mm，厚度仅为 12 mm，可轻松嵌入各种空间受限的应用场景。

低功耗： 采用低功耗设计，功耗低，发热量小，适用于对功耗要求严格的应用。

易于使用： 提供多种开发工具和支持，包括：Linux 操作系统：支持多种 Linux 发行版，可快速搭建开发环境。

开发套件：提供完整的开发套件，包括 SDK、示例代码和文档。

技术支持：提供专业的技术支持，帮助用户解决开发过程中的问题。

技术规格

型号：处理器01-01

处理器：恩智浦 i.MX 8M 加

主频：1.5千兆赫

架构：四核 ARM Cortex-A53

内存：1 GB 至 4 GB DDR4 内存

存储：8 GB 至 32 GB eMMC 闪存

接口：以太网：千兆以太网接口

USB：2 个 USB 3.0 接口

串口：2 个 RS-232/485 接口

CAN 总线：1 个 CAN 总线接口

GPIO：大量 GPIO 引脚

尺寸：90 x 60 x 12 毫米

工作温度：-40°C 至 +85°C

防护等级：IP30防护等级

重量：50 克

CPUX01-01 嵌入式控制单板计算机

summarize

The CPUX01-01 is an embedded control board computer based on the NXP i.MX 8M Plus processor. With its powerful processing power, rich features and small, compact size, it is suitable for a variety of industrial control, iot and edge computing applications.

Main function

Powerful processing power: Based on the NXP i.MX 8M Plus processor, the main frequency is up to 1.5 GHZ, and the quad-core ARM Cortex-A53 architecture provides powerful processing power to meet the needs of a variety of complex applications.

Rich functions: Supports a variety of interfaces and communication protocols, including: Ethernet: Gigabit Ethernet interface, support TCP/IP protocol stack.

USB: Two USB 3.0 ports, supporting high-speed data transmission.

Serial port: Two RS-232/485 ports for serial communication.

CAN bus: 1 CAN bus interface, support CAN bus communication.

GPIO: A large number of GPIO pins to expand various peripheral functions.

Small and compact size: 90 x 60 mm and only 12 mm thick, it can be easily embedded in a variety of space-constrained applications.

Low power consumption: Low power consumption design, low power consumption, small heat, suitable for the application of strict power consumption requirements.

Easy to use: Provides a variety of development tools and support, including: Linux operating system: supports a variety of Linux distributions, can quickly build a development environment.

Development Kit: Provides a complete development kit, including SDK, sample code, and documentation.

Technical support: Provide professional technical support to help users solve problems in the development process.

Technical specification

Model: Processor 01-01

Processor: NXP i.MX 8M plus

Main frequency: 1.5 GHZ

Architecture: quad-core ARM Cortex-A53

Memory: 1 GB to 4 GB DDR4 memory

Storage: 8 GB to 32 GB eMMC flash

Interface: Ethernet: Gigabit Ethernet interface

USB: Two USB 3.0 ports

Serial port: Two RS-232/485 ports

CAN bus: 1 CAN bus interface

GPIO: Large number of GPIO pins

Dimensions: 90 x 60 x 12 mm

Operating temperature: -40°C to +85°C

Protection level: IP30 protection level

Weight: 50g
