80VD100PD.C0000-01 再生制动模块。 该模块旨在将减速电机产生的动能转换为电能，这些电能可以反馈到电源或用于为其他设备供电。 这可以提高能源效率并减少电机机械制动器的磨损。

80VD100PD的主要特性。C0000-01 再生制动模块：

高额定功率：为强大的电机提供高达 100 kW 的再生制动功率。

四象限操作：支持电机工作范围所有四个象限的电机和制动操作。

高效率：将将高比例的电机动能转换为电能。

灵活的连接选项：可连接各种电源和储能设备。

紧凑型设计：节省控制柜空间。

电机保持制动器连接：

80VD100PD.C0000-01 再生制动模块可以连接到电机保持制动器，以在停电或其他紧急情况下提供备用制动机构。该模块可以给制动器的电容器充电，确保即使在断电的情况下也能踩下制动器。

接线图：

在图中，再生制动模块与电机相连，电源和电机保持制动器。模块的 DC+ 和 DC- 端子连接到电机的正负极，分别。模块的制动器+和制动端子连接到制动器的正负极，分别。

使用 80VD100PD 的优势。C0000-01 带电机保持制动连接的再生制动模块：

提高安全性：在电源故障或其他紧急情况下提供备用制动机构。

减少磨损：通过使用再生制动来减少电机机械制动器的磨损。

能源效率：通过将电机的动能转换为电能来提高能源效率。

80VD100PD.C0000-01 逆变模块 电机保持制动连接

80VD100PD.C0000-01 Regenerative braking module. The module is designed to convert kinetic energy generated by the gear motor into electrical energy, which can be fed back into a power supply or used to power other devices. This can improve energy efficiency and reduce wear on the motor's mechanical brakes.

Main features of 80VD100PD. C0000-01 Regenerative Brake Module:

High power rating: Up to 100 kW of regenerative braking power for powerful motors.

Four-quadrant operation: Supports motor and brake operation in all four quadrants of the motor operating range.

High efficiency: A high proportion of motor kinetic energy will be converted into electrical energy.

Flexible connection options: Various power and energy storage devices can be connected.

Compact design: Save control cabinet space.

Motor holding brake connection:

The 80VD100PD.C0000-01 regenerative brake module can be connected to the motor holding brake to provide a backup brake mechanism in case of a power outage or other emergency. The module can charge the capacitors of the brake, ensuring that the brake can be stepped on even in the case of power failure.

Wiring diagram:

In the picture, the regenerative brake module is connected to the motor, and the power supply and the motor hold the brake. The DC+ and DC-terminals of the module are connected to the positive and negative terminals of the motor, respectively. The module's brake + and brake terminals are connected to the positive and negative terminals of the brake, respectively.

The advantages of using 80VD100PD. C0000-01 Regenerative brake module with motor holding brake connection:

Improved safety: Provide backup braking mechanism in case of power failure or other emergency.

Reduce wear: Reduce wear on motor mechanical brakes by using regenerative braking.

Energy efficiency: Improve energy efficiency by converting kinetic energy from the motor into electrical energy.
