UNIOP TCM08A备件控制模块

UNIOP TCM08A备件控制模块

UNIOP TCM08A散热器输出侧测得的空气流量要求如下：大于450LFM。2.将VMIVME-7807/VME-7807RC插入VME机箱系统控制器，或外围插槽。同时确保板正确对齐和定向在支撑板导槽中，将板顺滑向前，抵住支撑板匹配连接器。

使用顶出器手柄使板牢固就位。3.可以从前面板或后I/O访问所有需要的外围设备VMIACC-0586/ACC-0586RC或VMIACC－0590/ACC－0590RC后过渡模块（RTM）。每个接头都清楚地标记在前面板上，并且详细的引脚说明见附录A。4.如果以前未安装过系统，请连接键盘和鼠标配置。5.VMIVME-7807/VME-7807RC具有可选的CompactFlash磁盘董事会成员。有关设置的详细信息

6.如果安装了外部驱动器模块，则必须使用BIOS设置程序来：配置驱动器类型。请参见附录B以正确配置系统。7.如果存在驱动模块，请根据安装说明安装操作系统制造商说明。VMIVME-7807/VME-7807RC具有板载BIOS设置程序许多配置选项。这些选项保存在特殊的非易失性文件中，电池支持的存储芯片，统称为电路板的“CMOS”配置'。CMOS配置控制着许多与电路有关的细节从施加功率的时刻起硬件的行为。

The UNIOP TCM08A radiator output side measured air flow requirements are as follows: greater than 450LFM. 2. Insert the VMIVME-7807 or VME-7807RC into the system controller or peripheral slot in the VME chassis. At the same time, ensure that the board is properly aligned and oriented in the guide groove of the support plate, slide the board forward, and hold the matching connector of the support plate.

Use ejector handle to secure plate in place. 3. All required peripherals VMIAC-0586 /ACC-0586RC or VMIAC-0590 /ACC-0590RC Rear Transition Module (RTM) can be accessed from front panel or rear I/O. Each connector is clearly marked on the front panel, and detailed pin instructions are in Appendix A. 4. If the system has not been installed before, connect the keyboard and mouse. 5.VMIVME-7807/VME-7807RC has optional CompactFlash disk board members. Details about the Settings

6. If an external drive module is installed, you must use the BIOS setup program to: configure the drive type. See Appendix B to configure the system correctly. 7. If a driver module exists, install the driver according to the OS manufacturer's instructions. The VMIVME-7807/VME-7807RC has many configuration options for the onboard BIOS setup program. These options are saved in special non-volatile files of the battery-supported memory chips, collectively referred to as the 'CMOS' configuration of the circuit board. CMOS configurations control many of the details related to the circuit from the moment power is applied to the hardware behavior.
