X2MARINE7 630002505 Beijer 人机界面

X2MARINE7 630002505 Beijer 人机界面

X2 Marine 7 是北尔电子推出的一款人机界面 （HMI） 面板，设计用于各种海事应用，包括导航、发动机控制和系统监控。它为操作员提供了一个用户友好的界面，可以与车载系统进行交互和控制，从而确保安全高效的操作。

X2 Marine 7 HMI 面板的主要特点：

船舶认证：符合严格的船舶认证，包括 DNV GL、KR、LR、ABS、CCS、BV、NK 和 RS，确保符合海上安全标准。

高亮度显示：配备高亮度 7 英寸 TFT-LCD 触摸屏显示屏，带防反射膜，即使在阳光直射下也能确保清晰可见。

坚固的结构：提供坚固的 IP65 级外壳，适用于恶劣的海洋环境，可承受灰尘、水、冲击和振动。

强大的处理器：配备强大的 ARM Cortex-A9 处理器，可实现快速屏幕更新和高效的应用程序执行。

多种 I/O 选项：支持多种通信接口和 I/O 选项，可与各种船舶系统和传感器集成。

X2 Marine 7 HMI面板的应用：

桥梁控制：为舰桥上的导航、通信和系统监控提供集中控制面板。

机舱控制：从发动机舱控制和监控发动机参数，例如速度、温度和油耗。

系统监控：监控和报警关键系统参数，例如舱底液位、配电和火灾探测。

货物装卸：控制和监控货物装卸操作，例如起重机控制、压载水管理和货物温度。

乘客舒适度：管理乘客舒适系统，例如照明、通风和娱乐系统。

使用 X2 Marine 7 HMI 面板：

安装：

将 X2 Marine 7 HMI 面板安装在船上的合适位置，确保正确对齐和可访问性。

按照用户手册中提供的接线图和规格将电源线连接到面板的电源端子。

将船用系统和传感器的通信电缆连接到面板的 I/O 端口。

配置：

使用北尔的HStudio软件配置X2 Marine 7 HMI面板，创建图形用户界面，设置控制参数，并定义报警阈值。

将面板集成到整个船舶的自动化系统中，建立通信协议、数据交换机制和报警管理程序。

测试和调试：

对 HMI 面板进行彻底测试以确保正常运行，包括显示功能、触摸灵敏度、通信链路和警报激活。

执行调试测试，以验证面板、船舶系统和船舶自动化网络之间的正确交互。

验证 HMI 系统在实际海上作业中的整体可用性、可靠性和安全性。

X2MARINE7 630002505 Beijer 人机界面

The X2 Marine 7 is a human machine interface (HMI) panel from Beier Electronics designed for use in a variety of maritime applications, including navigation, engine control and system monitoring. It provides operators with a user-friendly interface to interact with and control onboard systems, ensuring safe and efficient operation.

Key features of the X2 Marine 7 HMI panel:

Ship Certification: Compliance with stringent ship certifications including DNV GL, KR, LR, ABS, CCS, BV, NK and RS ensures compliance with maritime safety standards.

High Brightness display: High brightness 7-inch TFT-LCD touchscreen display with anti-reflective film ensures clear visibility even in direct sunlight.

Rugged construction: Provides a rugged IP65-rated housing for harsh Marine environments and withstands dust, water, shock and vibration.

Powerful processor: Equipped with a powerful ARM Cortex-A9 processor for fast screen updates and efficient application execution.

Multiple I/O options: Supports multiple communication interfaces and I/O options for integration with a wide range of ship systems and sensors.

X2 Marine 7 HMI Panel applications:

Bridge Control: Provides a centralized control panel for navigation, communication and system monitoring on the bridge.

Cabin control: Controls and monitors engine parameters such as speed, temperature and fuel consumption from the engine compartment.

System monitoring: Monitoring and alerting critical system parameters such as bilge level, power distribution and fire detection.

Cargo handling: Controls and monitors cargo handling operations such as crane control, ballast water management and cargo temperature.

Passenger comfort: Manage passenger comfort systems such as lighting, ventilation and entertainment systems.

Using the X2 Marine 7 HMI panel:

Installation:

Install the X2 Marine 7 HMI panel in the right position on the ship, ensuring proper alignment and accessibility.

Connect the power cable to the power terminal on the panel according to the wiring diagram and specifications provided in the user manual.

Connect communication cables for Marine systems and sensors to the panel's I/O ports.

Settings:

Use North's HStudio software to configure the X2 Marine 7 HMI panel, create a graphical user interface, set control parameters, and define alarm thresholds.

The panel is integrated into the automation system of the entire ship, establishing communication protocols, data exchange mechanisms and alarm management procedures.

Testing and debugging:

HMI panels are thoroughly tested to ensure proper operation, including display functionality, touch sensitivity, communication links, and alarm activation.

Perform commissioning tests to verify proper interaction between panels, ship systems, and ship automation networks.

Verify the overall availability, reliability and safety of the HMI system in actual offshore operations.

X2MARINE7 630002505 Beijer 人机界面
