工控产品METSO IOP302

工控产品METSO IOP302

METSO IOP302连接多个驱动器需要使用一个分支单元，这样可以：具有物理拓扑的逻辑总线的构造，请参见第页的图60 172.分支单元可以被链接。驱动器连接支持以下驱动器：ACS 600单驱动器ACS 600多驱动器

ACS 600晶闸管电源装置ACS 600 IGBT电源装置ACS 800产品系列ACS 140-AC S400DCS 600和DCS 400ACS 6000产品系列/大型驱动器AC 800M控制器的电源系统配置非常复杂直截了当配置给出了一系列简单电路显示连接输入电源的各种可能性的图表-通过电源断路器、电源装置和SS83X投票装置–连接至24伏直流配电终端。

AC 800M控制器及其I/O系统通常位于一个或多个位置外壳或机柜。安装AC 800M控制器的机柜也可以：包含通过电气模块总线连接到控制器的I/O单元光纤模块总线或PROFIBUS DP的通信接口

METSO IOP302 Connecting multiple drives requires the use of a branch unit, which allows: For the construction of a logical bus with a physical topology, see Figure 60 172 on page. Branch units can be linked. Drive connection supports the following drives: ACS 600 Single drive ACS 600 multi-drive

ACS 600 Thyristor Power Unit ACS 600 IGBT Power Unit ACS 800 Product Family ACS 140-AC S400DCS 600 and DCS 400ACS 6000 Product family/Large driver AC The 800M controller's power system configuration is very complex. The straightforward configuration gives a diagram of a series of simple circuits showing the various possibilities of connecting the input power - via the power circuit breaker, the power supply unit and the SS83X voting unit - to the 24 volt DC distribution terminal.

The AC 800M controller and its I/O system are usually located in one or more locations housing or cabinets. The cabinet where the AC 800M controller is installed can also: contain a communication interface for the I/O unit Optical Fiber module bus or PROFIBUS DP connected to the controller via the electrical module bus
