VMIVME-7696与VMIC的VMIACC-0561（VMEbus）兼容P2转换板），用于将SCSI信号路由到标准68针Ultra-SCSI-2连接器。

VMIVME-7696采用VMIC型号VMIVME-VMXC-7该电缆与其他CPU产品使用的电缆不同。增加的长度在用于CPU主板的连接器和中间连接器之间允许在安装VMIACC-0561时布线电缆。

以下是用于安装VMIVME-7696和VMIVME-7455的步骤：1.将VMIVME-7696 CPU板插入VMEbus机箱的所需插槽。2.将VMIVME-7455和可选VMIVME-7452插入所需插槽VMEbus机箱的一部分。3.将64芯电缆组件连接至P2的延伸引脚位于背板后部的连接器。3a。电缆必须安装到CPU的插槽中主板。3b。电缆的另一端必须安装到电缆占用的插槽中VMIVME-7455。3c。如果要使用VMIVME-7452，请安装位于中的接头将64芯电缆组件的中间插入相应的槽中。

The VMIVME-7696 is compatible with VMIC's VMIAC-0561 (VMEbus) P2 converter board for routing SCSI signals to a standard 68-pin Ultra-SCSI-2 connector.

VMIVME-7696 using VMIC model VMIVME-VMXC-7 This cable is different from the cable used in other CPU products. The increased length between the connector for the CPU motherboard and the intermediate connector allows cabling when installing the VMIAC-0561.

Here are the steps for installing VMIVME-7696 and VMIVME-7455:1. Insert the VMIVME-7696 CPU board into the desired slot in the VMEbus chassis. 2. Insert the VMIVME-7455 and optional VMIVME-7452 into a part of the VMEbus chassis. 3. Connect the 64-core cable assembly to the connector with the P2 extension pin located at the rear of the backplane. 3a. The cable must be installed into the CPU slot in the motherboard. 3b. The other end of the cable must be installed into the slot occupied by the cable VMIVME-7455. 3c. If you want to use the VMIVME-7452, insert the middle of the 64-core cable assembly into the appropriate slot by installing the connector located in the middle.
