ALSTOM 阿尔斯通控制板 V4561983-0100 V4559856

ALSTOM 阿尔斯通控制板   V4561983-0100 V4559856

功能说明

有两个独立的串口和一个 Intel Celeron-M微处理器。它的64 MB非易失性闪存补充了64MB电池支持的随机存取存储器(RAM)。还支持本地和远程扩展机架。CPU的串行背板设计与90-30系列I/O产品线中的扩展模块(但不与主机架)兼容。

使用Proficy Machine Edition，所有GE Fanuc控制器通用的开发环境。Proficy Machine Edition专门用于创建、运行和诊断操作员界面、运动和控制应用程序。

节省空间的CPU机箱上的八个LED指示灯有助于排除故障。每个LED都与一个单独的功能相关联，但标有COM1和COM2的两个LED除外,它们属于不同的端口而不是不同的功能。其他LED是CPU OK、Run、Outputs Enabled、I/O Force,Battery和 Sys Flt——这是“系统故障”的缩写。I/O Force LED指示Override是否在位参考上处于活动状态。其他LED标签是不言自明的。机箱设计将所有LED和两个串行端口都朝前,以便于访问和查看。

Function description

There are two separate serial ports and an Intel Celeron-M microprocessor. Its 64MB non-volatile flash memory complements the 64MB battery-supported random access memory (RAM). Local and remote extension racks are also supported. The CPU's serial backplane is designed to be compatible with expansion modules in the 90-30 series I/O product line (but not with mainframe racks).

Use Proficy Machine Edition, a common development environment for all GE Fanuc controllers. Proficy Machine Edition is designed to create, run, and diagnose operator interfaces, motion, and control applications.

Eight LED indicators on the space-saving CPU chassis help troubleshoot. Each LED is associated with a separate function, with the exception of the two leds labeled COM1 and COM2, which belong to different ports rather than different functions. The other leds are CPU OK, Run, Outputs Enabled, I/O Force,Battery, and Sys Flt - short for "system failure." I/O Force LED indicates whether Override is active on the present reference. Other LED labels are self-explanatory. The case is designed with all leds and two serial ports facing forward for easy access and viewing.
