MDX61B0220-5A3-4-00 伺服驱动器

MDX61B0220-5A3-4-00 伺服驱动器

MDX61B0220-5A3-4-00 伺服驱动器

MDX61B0220-5A3-4-00 是一款由 Yaskawa Motoman 生产的交流伺服驱动器，用于控制交流伺服电机。它具有以下特点：

高性能： MDX61B0220-5A3-4-00 采用高性能的 DSP 控制芯片，可提供高精度的速度和位置控制，以及快速的响应速度。

高可靠性： MDX61B0220-5A3-4-00 采用高品质的元件，并经过严格的测试，可确保长期可靠运行。

易于使用： MDX61B0220-5A3-4-00 提供多种参数设置方式，包括软件、触摸屏和 Modbus 通信，方便用户配置和调试。

应用

MDX61B0220-5A3-4-00 可广泛应用于各种工业控制和自动化应用，包括：

包装机械： 控制包装机的输送、分拣、码垛等运动。

印刷机械： 控制印刷机的纸张输送、张力控制等运动。

纺织机械： 控制纺织机的牵引、卷绕等运动。

机器人： 控制机器人的关节运动。

机床： 控制机床的进给、主轴等运动。

技术规格

参数 值

额定功率 2 千瓦

额定电压 380 伏交流电

额定电流 4.7 安培

速度控制范围 0 - 3000 转/分

位置控制精度 ±0.001 毫米

过载能力 150%

通信接口 Modbus RTU系统

尺寸 240 毫米 x 180 毫米 x 100 毫米

MDX61B0220-5A3-4-00 伺服驱动器

The MDX61B0220-5A3-4-00 is an AC servo drive manufactured by Yaskawa Motoman for the control of AC servo motors. It has the following characteristics:

High performance: MDX61B0220-5A3-4-00 adopts high performance DSP control chip to provide high precision speed and position control, as well as fast response speed.

High reliability: MDX61B0220-5A3-4-00 uses high-quality components and has undergone rigorous testing to ensure long-term reliable operation.

Easy to use: MDX61B0220-5A3-4-00 provides a variety of parameter Settings, including software, touch screen and Modbus communication, for easy configuration and debugging.

Apply

The MDX61B0220-5A3-4-00 can be used in a wide range of industrial control and automation applications, including:

Packaging machinery: control the transportation, sorting, palletizing and other movements of the packaging machine.

Printing machinery: control the movement of paper conveying and tension control of the printing press.

Textile machinery: control the traction, winding and other movements of the textile machine.

Robot: Controls the joint movement of the robot.

Machine tool: control machine feed, spindle and other movements.

Technical specification

Parameter value

Rated power 2 kW

Rated voltage 380 V AC

Rated current 4.7 amps

Speed control range 0-3000 RPM

Position control accuracy ±0.001 mm

Overload capacity 150%

Communication interface Modbus RTU system

Dimensions 240 mm x 180 mm x 100 mm
