UNITROL-1005-0011 励磁调接应用UNITROL系统电压控制器

作为UNITROL 1000系列的一部分，UNITROL 1005将范围扩展到低端励磁应用，最大励磁电流可达5 ADC。与所有UNITROL1000产品一样，UNITROL 1005基于相同的目标软件源代码，并共享相同的模拟模型，这使其非常适合要求苛刻的网格代码应用。软件包中包括CMT1000，这是一种用于集中和快速调试的工具。

UNITROL 1005将UNITROL 1000产品系列扩展到较小的当前范围。数字自动电压调节器（AVR）使用与UNITROL 1010和UNITROL 1020相同的软件，为任何苛刻的电网代码要求以及动态故障穿越（FRT）检测做好准备。UNITROL 1005免费提供调试和维护工具CMT 1000。

UNITROL 1005有两个软件版本。ECO软件包AVR/FCR/PF变量叠加PF/VAR调节器限定检索增压控制/FRT检测软启动电压匹配轻型软件包历史记录器：记录最后两个小时的操作

Modbus TCP协议

CMT 1000和其他工具免费调试和维护工具，CMT 1000PID整定工具电子学习

主要硬件功能

动力部件

基于IGBT的AVR输出级交流/直流输入晶闸管撬杆触发外部熔断器装置跳闸

测量

单相或三相机器电压单相机器电流

励磁电流

励磁电压

整流输入电压

UNITROL-1005-0011 励磁调接应用UNITROL系统电压控制器

As part of the UNITROL 1000 series, the UNITROL 1005 extends the range to low-end excitation applications with a maximum excitation current of up to 5 ADC. Like all UNITROL1000 products, UNITROL 1005 is based on the same target software source code and shares the same simulation model, making it ideal for demanding grid code applications. Included in the package is the CMT1000, a tool for centralized and fast debugging.

UNITROL 1005 extends the UNITROL 1000 product family to a smaller current range. The Digital Automatic Voltage Regulator (AVR) uses the same software as the UNITROL 1010 and UNITROL 1020 to prepare for any demanding grid code requirements as well as dynamic fault crossing (FRT) detection. UNITROL 1005 provides the CMT 1000 debugging and maintenance tool for free.

UNITROL 1005 comes in two software versions. ECO Package AVR/FCR/PF Variable Superposition PF/VAR regulator qualified Search Boost control /FRT Detection Soft Start Voltage Match Lightweight Package History Logger: Records last two hours of operation

Modbus TCP protocol

CMT 1000 and other tools Free debugging and maintenance tools, CMT 1000PID tuning tools e-learning

Main hardware function

Power unit

The IGBt-based AVR output stage AC/DC input thyristor pry rod triggers the trip of the external fuse device

measure

Single-phase or three-phase machine voltage Single-phase machine current

Exciting current

Excitation voltage

Rectified input voltage
