REF615可作为配电网中架空线和馈线的主保护，也可作为变压器等设备的后备保护。主要用于电力变电站、电厂等电力行业以及水泥、冶金、石化、汽车、半导体、造纸、烟草等工业用户，也可用于市政、机场、港口、房地产等行业。为满足用户需要，REF615可以提供7种标准配置的应用。保护逻辑和相关功能均针对中国市场需求进行了特别优化。保护控制功能齐全 集成弧光保护REF615提供带方向或无方向过流和接地故障保护，同时也支持过压、低电压、零序电压保护、热过负荷保护、灵敏接地保护及速断接地保护（包括间歇性接地保护）。此外，该装置还集成了灵活配置的多轮次重合闸功能，可实现重合闸前、后加速和手合加速功能。REF615加装可选配件，还可直接集成三个弧光保护通道。用户无需另外购置和安装弧光保护装置即可实现对开关柜断路器、电缆和母线室的弧光检测和快速保护。REF615支持当地和远方控制功能。用户通过装置面板上的控制按钮或者后台监控系统（SCADA）即可实现对断路器的分、合闸操作。为防止未授权用户误操作并保证用户按照相应权限操作，该装置定义了四个级别的操作权限：浏览者、操作员、工程师和管理员。不同级别用户使用不同的账号和密码登陆。这些权限设置适用于各种访问方式，包括装置面板操作，web访问及使用PCM600装置配置工具。基于IEC 61850设计 支持水平通信REF615支持IEC 61850规约从而真正实现站内智能设备间的相互通信，同时也支持工业标准Modbus 通信协议, 以及IEC 60870-5-103。REF615按照IEC 61850 规约设计，包括与后台监控系统的通信和保护装置之间的GOOSE水平通信并符合IEC 61850-8-1的各项规范。由于基于IEC 61850的全新平台开发，该装置实现IEC 61850通信无需任何附加通信规约转换器，真正达到IEC 61850所要求的通信效率和功能。传统的继电器附加通信模块往往是为了达到兼容新规约或升级旧系统的目的。基于IEC 61850，在系统运行过程中所有智能装置（IED）间的操控信号不断通过通信总线以GOOSE报文的形式传递。因此，这种互操作方案仅需通过装置内部设置实现，比传统的屏柜间硬接线更加经济和高效。

REF615 电桥电机板结构简单灵敏度高

The REF615 can be used as primary protection for overhead lines and feeders in the distribution network, as well as backup protection for equipment such as transformers. Mainly used in power substations, power plants and other power industry and cement, metallurgy, petrochemical, automobile, semiconductor, paper, tobacco and other industrial users, can also be used in municipal, airport, port, real estate and other industries. To meet user needs, the REF615 is available in seven standard configurations. The protection logic and related functions are optimized for the Chinese market. Full protection control Integrated arc protection The REF615 provides directional or no-directional overcurrent and ground fault protection, as well as over voltage, low voltage, zero sequence voltage protection, thermal overload protection, sensitive ground protection, and quick-break ground protection (including intermittent ground protection). In addition, the device also integrates the multi-turn reclosing function with flexible configuration, which can realize the pre-reclosing acceleration, post-reclosing acceleration and hand acceleration. The REF615 comes with optional accessories and directly integrates three arc protection channels. Users do not need to purchase and install arc protection devices to realize the arc detection and rapid protection of switchgear circuit breakers, cables and bus rooms. The REF615 supports local and remote control. The user can operate the circuit breaker through the control button on the panel of the device or the background monitoring system (SCADA). In order to prevent unauthorized users from misoperating and ensure that users operate according to the appropriate permissions, the device defines four levels of operation permissions: viewer, operator, engineer and administrator. Different levels of users use different accounts and passwords to log in. These permissions are set for a variety of access methods, including device panel operations, web access, and using the PCM600 device Configuration tool. Based on IEC 61850 design support for horizontal communication REF615 supports the IEC 61850 protocol for true communication between intelligent devices in the station, as well as the industry standard Modbus communication protocol, as well as IEC 60870-5-103. The REF615 is designed according to IEC 61850 specifications, including GOOSE horizontal communication with the back office monitoring system and protection devices, and complies with IEC 61850-8-1 specifications. Due to the new platform development based on IEC 61850, the device implements IEC 61850 communication without any additional communication protocol converter, truly achieving the communication efficiency and functionality required by IEC 61850. The traditional relay attached communication module is often to achieve compatibility with the new protocol or upgrade the old system. Based on IEC 61850, the control signals between all intelligent devices (IEDs) during the operation of the system are continuously transmitted through the communication bus in the form of GOOSE messages. Therefore, this interoperation scheme only needs to be implemented through the internal setup of the device, which is more economical and efficient than the traditional hardwiring between the screen cabinets.
