FI830F SA801F FI820FPLC-模拟量输入模块 控制器模块

FI830F SA801F FI820FPLC-模拟量输入模块 控制器模块

CPU主板包含微处理器和RAM、实时时钟、LED指示灯、启动按钮和紧凑型闪存接口。

PM856A控制器的底板有两个RJ45以太网端口(CN1、CN2)用于连接到控制网络，以及两个RJ45串行端口(COM3、COM4)。其中一个串行端口(COM3)是带有调制解调器控制信号的RS-232C端口，而另一个端口(COM4)则被隔离并用于连接配置工具。

简单DIN轨道连接/卸料程序，使用的滑道&锁机构。所有base plates都有的以太网地址，每个CPU都有一个硬件标识。地址可以在连接到TP830 base plate的以太网地址标签上找到。

功能与优点

可靠性和简单故障诊断程序

模块化，允许逐步扩展

IP20类保护，不需要存储模块

控制器可配置为800xA control builder

控制器已获得完整的EMC认证

基于标准的硬件，用于实现佳通信连接(以太网、PROFIBUS DP等)。

FI830F SA801F FI820FPLC-模拟量输入模块 控制器模块

The CPU motherboard contains a microprocessor and RAM, a real-time clock, LED indicators, a start button, and a compact flash interface.

The baseplate of the PM856A controller has two RJ45 Ethernet ports (CN1, CN2) for connecting to the control network, and two RJ45 serial ports (COM3, COM4). One of the serial ports (COM3) is the RS-232C port with the modem control signal, while the other port (COM4) is isolated and used to connect to the configuration tool.

Simple DIN track connection/discharge procedure, using slide & lock mechanism. All base plates have Ethernet addresses, and each CPU has a hardware ID. The address can be found on the Ethernet address label connected to the TP830 base plate.

Functions and benefits

Reliability and simple fault diagnosis program

Modular, allowing for gradual expansion

IP20 protection: no storage module is required

The controller can be configured as 800xA control builder

The controller has obtained full EMC certification

Standards-based hardware for good communication connectivity (Ethernet, PROFIBUS DP, etc.).
