产品介绍

型号名称：3BHE024747R0101

技术性能及指标

1 X轴系统

A.工作方式:分集电极电压(Vc),基极电压(Vb),二极管电压(Vd)和阶梯信号四类.

B.位移范围:大于10度

C.集电极电压偏转因数:20mV/度 ～ 20V/度. 1-2-5序共10挡 误差≤±3%

D.基极电压偏转因数:20mV/度 ～ 1V/度. 1-2-5序共6挡 误差≤±3%

E.二极管电压偏转因数:100V/度 ～ 500V/度. 1-2-5序共3挡 误差≤±3%

F.阶梯信号偏转因数:1阶/度 误差≤±5%

2 Y轴系统

A.工作方式:分集电极流(Ic),三端稳压电路输出电压,和阶梯信号三类.

B.位移范围:大于10度

C.集电极电流偏转因数:10uA/度～ 2A/度. 1-2-5序共17挡 误差≤±3%

D.三端稳压电路输出电压:1V/度～ 5V/度. 1-2-5序共3挡 误差≤±3%

E.阶梯信号偏转因数:1阶/度 误差≤±5%

3 阶梯信号源

A.工作方式:分恒压源和恒流源两类

B:极性:正或负

C:阶梯电流源:1mA ～ 200mA/阶 1-2-5序共17挡 误差≤±5%

D:阶梯电压源:20mV/度 ～ 1V/度 1-2-5序共6挡 误差≤±5% (源内阻100Ω)

E:级/族:1-10 连续步进

3BHE024747R0101 自动化处理器模块 800xA系统备件

Product introduction

Model name: 3BHE024747R0101

Technical performance and index

1 X axis system

A. Working mode: Diversity electrode voltage (Vc), base voltage (Vb), diode voltage (Vd) and step signal four categories.

B. Displacement range: greater than 10 degrees

C. Collector voltage deflection factor :20mV/ degree ~ 20V/ degree. 1-2-5 sequence a total of 10 stops error ≤±3%

D. Base voltage deflection factor :20mV/ degree ~ 1V/ degree. 1-2-5 sequence a total of 6 stops error ≤±3%

E. Diode voltage deflection factor :100V/ degree ~ 500V/ degree. 1-2-5 sequence a total of 3 stops error ≤±3%

F. Step signal deflection factor :1 order/degree error ≤±5%

2 Y-axis system

A. Working mode: Diversity electrode flow (Ic), three-terminal voltage regulator circuit output voltage, and step signal three classes.

B. Displacement range: greater than 10 degrees

C. Collector current deflection factor :10uA/ degree ~ 2A/ degree. 1-2-5 sequence a total of 17 stops error ≤±3%

D. Three-terminal voltage regulator circuit output voltage :1V/ degree ~ 5V/ degree. 1-2-5 sequence a total of 3 stops error ≤±3%

E. Step signal deflection factor :1 order/degree error ≤±5%

3 Step signal source

A. Working mode: constant voltage source and constant current source two types

B: Polarity: positive or negative

C: Step current source :1mA ~ 200mA/ 1-2-5 sequence A total of 17 stops error ≤±5%

D: Step voltage source :20mV/ degree ~ 1V/ degree 1-2-5 Sequence a total of 6 stops error ≤±5% (source internal resistance 100Ω)

E: Class/family :1-10 continuous step
