·涉及哪种类型的工艺,(造纸、转化等)?环境要求高吗（温度、化学品等)?·张力测量的目的是什么;指示还是闭环控制Q?是否涉及任何特定的精度要求?

·机器的设计是什么样的?是否有可能修改设计以安装最合适的称重传感器О，或者机器设计是否固定?

·作用在丈上的力是什么样的(大小和方向)﹖它们可以通过重新设计来改变吗?如果这些问题得到彻底解决，安装就很有可能成功。然而，在设计称重传感器安装时，需要测量精度的程度定义了要求。

以下程序定义了称重传感器安装设计中涉及的主要注意事项。1.检查称重传感器数据，以满足环境要求。

2.计算力;垂直、水平和轴向（横向)。

3.确定称重传感器的尺寸和方向，以满足以下指南: a.在称重传感器的测星方向上，尽星达到不小于腹板张力10%的测星值! b选择称重传感器的尺寸，使其负载尽可能接近其标称负载!测量方向上的张力分力FR的尺寸不得小于称重传感器标称载荷的10%! c.如果过程中最大和最小张力之间的跨度较大，请选择测压元件，张力处于测压元件扩展范围内(如适用)! d.卷筒纸张力的测量分力建议至少为称重传感器测星方向上皮重分力(卷筒重星)的30%。此建议的原因是称重传感器信号的稳定性，尤其是当系统在大的温度范围内运行时。这意味着，如果FRT<Fnom的1/3，则FR应至少为Fnom。对于较大的FRT，建议最低FR至少为FRT的30%。

1SAP250100R0001 ABB 张力处于测压元件扩展范围内

What type of process is involved (paper making, conversion, etc.)? Are the environmental requirements high (temperature, chemicals, etc.)? · What is the purpose of tension measurement; Indication or closed loop control Q? Are there any specific accuracy requirements involved?

· What is the design of the machine? Is it possible to modify the design to install the most suitable load cell, or is the machine design fixed?

· What is the force acting on the meter (magnitude and direction)? Can they be changed by redesign? If these issues are completely resolved, the installation is likely to be successful. However, when designing a load cell installation, the degree of measurement accuracy required defines the requirements.

The following procedure defines the main considerations involved in the design of a load cell installation. 1. Check the load cell data to meet environmental requirements.

2. Calculation power; Vertical, horizontal, and axial (horizontal).

3. Determine the size and orientation of the load cell to meet the following guidelines: a. In the star measurement direction of the load cell, the star reaches the star measurement value of not less than 10% of the web tension! b Choose the size of the load sensor so that its load is as close to its nominal load as possible! The dimension of the tension component FR in the measurement direction shall not be less than 10% of the nominal load of the load cell! c. If the span between the maximum and minimum tension in the process is large, select the load cell, the tension is within the load cell expansion range (if applicable)! d. The measurement component of the web tension is recommended to be at least 30% of the tare weight component (the web weight star) in the direction of the load sensor. The reason for this recommendation is the stability of the load cell signal, especially when the system is operating over a large temperature range. This means that if FRT< 1/3 of Fnom, the FR should be at least Fnom. For larger FRTS, a minimum FR of at least 30% of the FRT is recommended.
