PCD231B101系列90-70 PLC硬件基本组成

一个典型的系列90-70 PLC系统配置包括:1种类型的CPU模块家族(最新一代的CPU由6种组成类型)5种底板框架可供选择。电源模块。总线扩展模块包括: (BUS Transmitter)总线传输模块，总线接收模块(BUS Receriver)远程I/O扫描模块(Remote I/O Scanner)。机架安装型开关量模拟量I/O模块。

分布式的Genius I/O的系统,Field Control系统。可编程协处理器模块(PCM)。高速计数器模块。

CPU 和PCM模块内存扩展单元。Genius总线控制模块。

TCP/IP Ethernet 通讯处理器模块。I/O Link 界面模块可联接GE Fanuc 和Fanuc其它产品。第三厂家VME模块。

PCD231B101 ABB  励磁控制模块 可编程协处理器

PCD231B101 series 90-70 PLC hardware basic composition

A typical series 90-70 PLC system configuration includes :1 type of CPU module family (the latest generation of cpus consists of 6 component types)5 backboard frames to choose from. Power module. The BUS expansion module includes: BUS Transmitter bus transmission module, BUS Receriver bus I/O scanning module (Remote I/O Scanner). Rack-mounted switching analog I/O module.

Distributed Genius I/O system,Field Control system. Programmable coprocessor module (PCM). High speed counter module.

CPU and PCM module memory expansion unit. Genius Bus control module.

TCP/IP Ethernet communication processor module. I/O Link interface modules can be connected to GE Fanuc and other Fanuc products. The third manufacturer VME module.
