一、干式变压器简介

CI858K01 3BSE018135R1干式变压器是依靠空气对流进行冷却，一般用于局部照明、电子线路。干式变压器广泛用于局部照明、高层建筑、机场，码头CNC机械设备等场所，简单的说干式变压器就是指铁芯和绕组不浸渍在绝缘油中的变压器。冷却方式分为自然空气冷却(AN)和强迫空气冷却(AF)。自然空冷时，变压器可在额定容量下长期连续运行。强迫风冷时，变压器输出容量可提高50%。适用于断续过负荷运行，或应急事故过负荷运行;由于过负荷时负载损耗和阻抗电压增幅较大，处于非经济运行状态，故不应使其处于长时间连续过负荷运行。

二、干式变压器的分类

CI858K01 3BSE018135R1干式变压器是铁芯和绕组均不浸于绝缘液体中的变压器，用于一般公共配电网或工业电网中，其可分为下面三类：

(1)全封闭干式变压器：置于无压力的密封外壳内，通过内部空气循环进行冷却的变压器。

(2)封闭干式变压器：置于通风的外壳内，通过外部空气循环进行冷却的变压器。

(3)非封闭干式变压器：不带防护外壳，通过空气自然循环或强迫空气循环进行冷却的变压器。

CI858K01 ABB  用于局部照明 电子线路

Introduction to dry transformer

CI858K01 3BSE018135R1 dry transformers rely on air convection for cooling, generally used for local lighting, electronic lines. Dry transformers are widely used in local lighting, high-rise buildings, airports, terminals, CNC machinery and equipment and other places, simply said dry transformers refers to the iron core and winding is not impregnated in insulation oil transformer. Cooling methods are divided into natural air cooling (AN) and forced air cooling (AF). When air cooled naturally, the transformer can run continuously for a long time under the rated capacity. When forced air cooling, the transformer output capacity can be increased by 50%. Suitable for intermittent overload operation, or emergency overload operation; Due to the large increase in load loss and impedance voltage during overload, it is in a non-economic operation state, so it should not be kept in continuous overload operation for a long time.

Second, the classification of dry transformers

CI858K01 3BSE018135R1 dry transformer is a transformer whose iron core and winding are not immersed in insulating liquid, which is used in general public distribution networks or industrial power grids, which can be divided into the following three categories:

(1) Fully enclosed dry transformer: a transformer placed in a pressure-free sealed enclosure and cooled by internal air circulation.

(2) Closed dry transformer: a transformer placed in a ventilated enclosure and cooled by external air circulation.

(3) Non-enclosed dry transformer: without protective housing, through the natural circulation of air or forced air circulation for cooling transformer.
