PPD113B01-10-150000 3BHE023784R0123 中央控制系统

PPD113B01-10-150000 3BHE023784R0123 中央控制系统

第一个连接器是前面板上的 68 针公连接器，上面印有 To Next Chassis。下一个连接器是前面板上的另一个 68 针公连接器，上面印有 From DAQ Board 或 Previous Chassis。第三个连接器是印刷电路板上的 50 针公分线连接器。最后一个连接器也是 50 针连接器，但它是电缆适配器背面的支架安装母头。

使用NI SCXI 1346在多机箱系统中，需要以下物品：一台计算机、一把小平头螺丝刀、68 针屏蔽电缆、一个 68 针 E 系列 DAQ 设备、一个 SCXI 1001 或 SCXI 1000 机箱（版本 K 或更高版本）、一个每个机箱的或更多 SCXI 模块（SCXI-1127、SCXI-1190 和 SCXI-1191 除外）、SCXI 1349 屏蔽电缆组件和 SCXI-1346 安装指南。用户应牢记在多机箱 SCXI 系统中使用的总电缆长度不要超过 10 m。这将有助于确保可靠的操作。

PPD113B01-10-150000 3BHE023784R0123 中央控制系统

The first connector is a 68-pin male connector on the front panel, printed To Next Chassis. The next connector is another 68-pin male connector on the front panel, printed From the DAQ Board or Previous Chassis. The third connector is a 50-pin cm wire connector on a printed circuit board. The last connector is also a 50-pin connector, but it is the bracket mounting female head on the back of the cable adapter.

With the NI SCXI 1346 in a multi-chassis system, the following items are required: One computer, one small flat-head screwdriver, 68-pin shielded cable, one 68-pin E-Series DAQ device, one SCXI 1001 or SCXI 1000 chassis (version K or later), one or more SCXI for each chassis Modules (except SCXI-1127, SCXI-1190, and SCXI-1191), SCXI 1349 Shielded Cable Assembly, and SCXI-1346 Installation Guide. Users should keep in mind that the total cable length used in a multi-chassis SCXI system should not exceed 10 m. This will help ensure reliable operation.

PPD113B01-10-150000 3BHE023784R0123 中央控制系统
