1、 算术逻辑运算单元ALU(Arithmetic and Logic Unit)

ALU主要完成对二进制数据的定点算术运算(加减乘除)、逻辑运算(与或非异或)以及移位操作。在某些CPU中还有专门用于处理移位操作的移位器。

通常ALU由两个输入端和一个输出端。整数单元有时也称为IEU(Integer ExecuTIon Unit)。我们通常所说的“CPU是XX位的”就是指ALU所能处理的数据的位数。

2、 浮点运算单元FPU(FloaTIng Point Unit)

FPU主要负责浮点运算和高精度整数运算。有些FPU还具有向量运算的功能，另外一些则有专门的向量处理单元。计算机系统的硬件结构主要由四部分组成：控制器、运算器、内存和输入输出设备，其中，控制器和运算器统称为中央处理器。简称CPU.它是计算机硬件系统的指挥中心.它包括控制器和运算器两个部件,其中,控制器的功能是控制计算机各部分协调工作,运算器则是负责计算机的算术运算和逻辑运算。
