ABB RXEDK 2H 1MRK 000 841-KA 时间过电压继电器

ABB RXEDK 2H 1MRK 000 841-KA 时间过电压继电器

ABB RXEDK 2H 1MRK 000 841-KA 时间过电压继电器

1．电磁继电器

在输入电路内电流的作用下，由机械部件的相对运动产生预定响应的一种继电器。

它包括直流电磁继电器、交流电磁继电器、磁保持继电器、极化继电器、舌簧继电器,节能功率继电器。

(1)直流电磁继电器：输入电路中的控制电流为直流的电磁继电器。

(2)交流电磁继电器：输入电路中的控制电流为交流的电磁继电器。

(3)磁保持继电器：将磁钢引入磁回路，继电器线圈断电后，继电器的衔铁仍能保持在线圈通电时的状态，具有两个稳定状态。

(4)极化继电器：状态改变取决于输入激励量极性的一种直流继电器。

(5)舌簧继电器：利用密封在管内，具有触点簧片和衔铁磁路双重作用的舌簧的动作来开、闭或转换线路的继电器。

(6)节能功率继电器:输入电路中的控制电流为交流的电磁继电器,但它的电流大(一般30-100A),体积小, 节电功能.

ABB RXEDK 2H 1MRK 000 841-KA 时间过电压继电器

1. Electromagnetic relay

A relay in which a predetermined response is generated by the relative movement of mechanical components under the action of current in the input circuit.

It includes DC electromagnetic relay, AC electromagnetic relay, magnetic holding relay, polarization relay, reed relay, energy saving power relay.

(1) DC electromagnetic relay: The control current in the input circuit is DC electromagnetic relay.

(2) AC electromagnetic relay: the control current in the input circuit is an AC electromagnetic relay.

(3) Magnetic holding relay: the magnetic steel is introduced into the magnetic circuit, and after the relay coil is powered off, the armature of the relay can still maintain the state when the coil is powered on, with two stable states.

(4) Polarized relay: a DC relay whose state changes depending on the polarity of the input excitation.

(5) Reed relay: Use the action of the reed sealed in the tube, with the dual role of the contact reed and the armature magnetic circuit to open, close or convert the line of the relay.

(6) Energy-saving power relay: the control current in the input circuit is an AC electromagnetic relay, but its current is large (generally 30-100A), small size, and power-saving function.
