ABB PXAH401 3BSE017235R1 控制模块 DCS PLC系统原装进口

ABB PXAH401 3BSE017235R1 控制模块 DCS PLC系统原装进口

ABB PXAH401 3BSE017235R1 控制模块 DCS PLC系统原装进口

PXAH401 3BSE017235R1 收集各种信号，并进行剖析、存储和显示。收集站只能作波形、频谱和趋势等简略剖析，而其他复杂的剖析和毛病确诊就要在作业站才干进行，这种分工最大限度地简化收集站上的操作，保证其数据收集和存储的可靠性。

作业站可为任何处于控制室、办公室甚至远在千里之外的运行Windows操作体系的计算机，只要此计算机可通过网络与收集站衔接并装置作业站软件。在作业站上可实时监测现场设备的运行状况、对历史数据进行毛病剖析确诊、备份历史数据、修正体系参数、备份体系参数、晋级体系程序等。

如果测点较多，收集站数量多于4个，或一起作业的作业站数量较多，为进步体系处理性能，可增设数据服务器。数据服务器接纳、处理和存储收集站的实时数据，一起为作业站供给数据服务。

特点

硬件选用模块化结构，装置、保护、替换便利，可靠性好。每个振动量模板为4路，模拟量板和开关量板均为32路，可任意组合配置。其中某一通道或某一模块毛病不会影响其他通道或其他模块正常作业，用户仅需自行替换产生毛病的模块即可解决此类毛病（我公司会供给一定量的模块备件）。

为开放式结构，用户能够将长期运行保护中堆集的经验和知识加入知识库。

除了一般振动剖析体系所具有的各种振动图谱外，还有自己的特有功能，如：

◇轴系运动仿真图

◇相关趋势剖析（横坐标和纵坐标可任意选，时间段可任◇意设定）

◇多种动平衡计算

◇齐备的数据库管理

◇远程确诊剖析等等

ABB PXAH401 3BSE017235R1 控制模块 DCS PLC系统原装进口

The PXAH401 3BSE017235R1 collects various signals and parses, stores and displays them. The collection station can only be a brief analysis of waveform, spectrum and trend, and other complex analysis and fault diagnosis must be carried out in the operation station, this division of labor to maximize the simplification of the operation of the collection station, to ensure the reliability of its data collection and storage.

The station can be any computer running Windows operating system in the control room, office or even thousands of miles away, as long as the computer can connect to the collection station through the network and install the station software. The operation station can monitor the operation status of the field equipment in real time, analyze and confirm the fault of the historical data, backup the historical data, modify the system parameters, backup system parameters, and promote the system procedures.

If there are more measurement points, more than 4 collection stations, or more work stations working together, in order to improve the system processing performance, data servers can be added. The data server receives, processes and stores the real-time data of the collection station, and provides data services for the operation station together.

peculiarity

The hardware adopts modular structure, convenient installation, protection and replacement, and good reliability. Each vibration quantity template has 4 channels, and both analog and switching quantity plates have 32 channels, which can be configured in any combination. The fault of one channel or one module will not affect the normal operation of other channels or other modules, and the user only needs to replace the faulty module by himself to solve such problems (our company will provide a certain amount of spare parts for the module).

The open structure allows users to add experience and knowledge accumulated in long-term operational protection to the knowledge base.

In addition to the various vibration graphs of the general vibration analysis system, it also has its own unique functions, such as:

◇ Shafting motion simulation diagram

◇ Correlation trend analysis (horizontal and vertical coordinates can be selected, time period can be set at will)

◇ A variety of dynamic balance calculation

◇ Complete database management

◇ Remote diagnosis analysis and so on
