功用阐明

1.开机时进行12段LED检查，当12颗LED透过跑马灯方式亮过一次，表明12颗LED皆无故障，待机正常。

2.供给12段负载断线检知，1-12段皆可自由挑选与调配，例如挑选2段或6段进行负载检知，没有运用到的部份，关掉指拨开关就不会启动检知功用。供给多段的指拨开关启动与关闭断线检知功用，更符合不同的运用环境调配。

3.外接LED指示灯，透过排线的连接可以延伸1-2m，同步控制板上的12颗LED指示灯功用，经由排线可以连接到设备显着的地方，例如控制箱外表，设备的操作面板，让作业人员可以即时的把握设备情况。

4. 供给两种机种挑选; 检知SCR电力调整器，检知SSR固态继电器。

5. 透过CT比流器与温度表互相承认，来判断负载是否有断线。

三.标准阐明

1、辅助电压: AC 220V ±15% 50/60Hz

2、作业频率: 50-60Hz ±5%

3、机种挑选：检知SCR电力调整器，检知SSR固态继电器。 （订货同时请告知事务）

4、运用环境: -10 度-50 度 湿度 90%RH以下

5、调配温度表接纳信号: 4-20mA, 0-5V, 1-5V

6、调配SSR温度表: NO-OFF

PFSK152 3BSE018877R2 3BSC980006R361通讯模块ABB

Function elucidation

1. 12 LED checks are carried out when the machine is turned on. When the 12 LED lights are lit once through the running lamp, it indicates that the 12 LED is fault-free and the standby is normal.

2. Supply 12 sections of load break detection, 1-12 sections can be freely selected and deployed, for example, select 2 sections or 6 sections of load detection, the part that is not used, turn off the dial switch will not start the detection function. The function of providing multi-section dial switch to start and close break line detection is more in line with different operating environments.

3. External LED indicator light, through the wiring connection can be extended 1-2m, synchronous control board on the 12 LED indicator function, through the wiring can be connected to the equipment significant places, such as the control box appearance, the operation panel of the equipment, so that the operator can immediately grasp the equipment situation.

4. Supply two kinds of machine selection; SCR power regulator detected, SSR solid state relay detected.

5. Through the mutual recognition of CT flow comparator and thermometer, to judge whether the load is broken.

Iii. Standard clarification

1, auxiliary voltage: AC 220V ±15% 50/60Hz

2, operating frequency: 50-60Hz ±5%

3, machine selection: Detect SCR power regulator, detect SSR solid-state relay. (Please inform business when ordering)

4, the application environment: -10 degrees -50 degrees humidity below 90%RH

5, adjust the thermometer reception signal: 4-20mA, 0-5V, 1-5V

6. Deploy the SSR thermometer: NO-OFF
