产品说明

DSTD108 57160001-ABD数模转换卡件电源架设计为在整个分布式电源中作为关键元件运行系统该电源架最多可容纳三个电源组，提供物理保护和报警和控制功能的数量。

电源架可提供多达1500 W的n+1冗余电源，或总计2250 W的电源功率取决于电源组的配置。四个叠层电源架可提供总功率高达9000 W。电源架可以与任何标准全局线电压一起使用。

标准交流输入通过三夹式IEC 60320型连接器连接到电源架欧洲/亚洲额定为10 A/250 Vac，北美额定为15 A/120 Vac。电源架有两个用于直流输出的接线板（每个接线板带有三个M4螺钉）。V型车+和V-相对于机架GND浮动，其中任何一个都可以作为要求在使用多个电源机架的系统中，机架应连接其CS使用电源架互连电缆TC-323。

这确保电源搁置当前共享。请勿在“A”和“B”电源之间或两组连接到单独母线的托架。电源将尝试共享电流这可能会损坏电源组和机架的感应电路。应将TC-323电缆上未使用的连接器绑起来，不使用。

ABB DSTD108 57160001-ABD嵌入式DCS智能通讯控制板

Product description

The DSTD108 57160001-ABD Digital to analog converter card power rack is designed to operate as a key element in the entire distributed power supply system. The power rack can accommodate up to three power packs, providing physical protection and a number of alarm and control functions.

The power rack provides up to 1500 W of n+1 redundant power, or a total of 2250 W of power depending on the configuration of the power pack. Four laminated power racks provide a total power of up to 9000 W. The power supply rack can be used with any standard global line voltage.

The standard AC input is connected to the power rack via A three-clip IEC 60320 type connector rated 10 A/250 Vac in Europe/Asia and 15 A/120 Vac in North America. The power supply frame has two power strips for DC output (each with three M4 screws). The V car + and V- float relative to the rack GND, either of which can be used as a requirement in a system using multiple power racks, the racks should be connected to their CS using the power rack interconnect cable TC-323.

This ensures that power is currently shared on hold. Do not use brackets between "A" and "B" power supplies or two sets connected to separate busbars. The power supply will attempt to share current which may damage the power pack and the rack's induction circuit. The unused connectors on the TC-323 cable should be tied and not used.
