ABB CM772F 3BDH000368R0001 PROFIBUS DP 主站模块

ABB CM772F 3BDH000368R0001 PROFIBUS DP 主站模块

ABB CM772F 3BDH000368R0001 PROFIBUS DP 主站模块

主要技术参数

1、电源:DC24V输入

2、4路隔离PWM脉冲输出,控制4路电机驱动器

3、4路隔离方向控制DO输出,控制4路电机方向

4、4路隔离使能控制DO输出，控制4路电机使能

5、4组限位控制输入:每组包括左限位DI输入、右限位DI输入、原点DI输入

6、一路隔离485总线,外接外部无线模块，接收遥控指令

7、2路正交编码器输入，反馈左右电机的运动轨迹

8、4路急停DI信号，以实现迅速停止电机运转

9、4路继电器输出(DC24V,驱动电磁阀)

10、工控板应满足工作现场电机的强电磁干扰要求，不死机。

11.温度要求:-20C~70c°

ABB CM772F 3BDH000368R0001 PROFIBUS DP 主站模块

Main technical parameters

1. Power supply :DC24V input

2, 4 isolated PWM pulse output, control 4 motor drivers

3, 4 isolation direction control DO output, control 4 motor direction

4, 4 isolation enable control DO output, control 4 motor enable

5, 4 groups of limit control input: each group includes left limit DI input, right limit DI input, origin DI input

6, one way isolation 485 bus, external wireless module, receive remote control instructions

7, 2 orthogonal encoder input, feedback around the motor trajectory

8, 4 emergency stop DI signal to achieve rapid stop of motor operation

9, 4 relay output (DC24V, drive solenoid valve)

10, the industrial control board should meet the requirements of strong electromagnetic interference of the motor at the work site, and do not crash.

11. Temperature :-20C~70c°
