技术规范

 CPU板上集成供电单元、CPU处理器及内存

五款不同的控制器类型共用户选择

分别为PM851、PM856、PM860、PM861、PM864

内存存储运行Firmware，控制单元硬件配置信息及应用程序

支持12个现场总线模块扩展

集成2个Ethernet接口，2个RS232C接口，ModulBus电气及光纤扩展接口

支持冗余设置，减少故障点错误并控制系统运行效率

多至16个任务，小任务周期1ms，SOE顺序发生事件分辨率<1ms

CPU可以通过以太网接口实现控制器级的通信，2个以太网口可设置为冗余，并内置冗余切换程序，用于提高系统可靠性。

Technical specification

The CPU board integrates the power supply unit, CPU processor, and memory

Five different controller types are available for users to choose from

They are PM851, PM856, PM860, PM861, and PM864

The memory stores Firmware, control unit hardware configuration information, and applications

Supports 12 fieldbus module extensions

Integrate 2 Ethernet interfaces, 2 RS232C interfaces, ModulBus electrical and optical fiber expansion interfaces

Support redundant Settings to reduce point of failure errors and control system operating efficiency

Up to 16 tasks, small task cycle 1ms, SOE sequence event resolution <1ms

The CPU implements controller-level communication through Ethernet interfaces. The two Ethernet ports can be configured as redundant ports, and a redundancy switching program is built in to improve system reliability.
