Excitation system is an indispensable part of power plant equipment. The excitation system includes an exciting power supply and an exciting device, wherein the main body of the exciting power supply is an exciter or an exciting transformer; According to different specifications, models and use requirements, the excitation device is composed of adjustment screen, control screen, magnetic screen and rectifier screen.

The use of the excitation device is to maintain the terminal voltage of the synchronous generator at a given level when the power system is working normally, and at the same time, it also has the function of forced magnetization, magnetization and magnetization. For the excitation transformer as the excitation power supply also has the rectification function. The excitation device can be supplied separately or as a power generation equipment.

Small and medium-sized hydraulic power generation equipment has implemented the export product quality licensing system, and products without export quality licenses are not allowed to export.

Application field

With the continuous increase of generator capacity and power grid, power systems and generator sets require excitation systems to have better control and regulation performance, more and more flexible control, restriction, alarm and other additional functions. In order to meet the above requirements, the microcomputer controlled digital excitation regulator came into being. The wide application of microcomputer excitation regulator greatly improves the safety, reliability and economic benefit of power plant production. The majority of small and medium-sized unit users are also in urgent need of a cheap, excellent performance, simple structure, easy to master, high reliability of the excitation regulator.

Because the design parameters of the excitation device are closely related to the parameters of the synchronous generator and the excitation power supply, the user who orders the excitation device separately should provide or fill in the technical parameters of the power generation equipment used with the excitation device, such as the synchronous generator and the excitation power supply, to ensure the uniform compatibility and performance of the product.

The excitation device should be installed indoors according to the regulations, so its use of ambient temperature, relative humidity, altitude and so on have certain requirements. Attention should be paid to transportation, storage and use. For the special requirements of performance and conditions of use, the user should be clearly stated at the time of signing.
