ABB G2010 A 10.4ST HC800备件

ABB G2010 A 10.4ST  HC800备件

G2010 A 10.4ST每个车窗都可以编程操作在耦合或解耦模式下。在解耦模式下窗口利用写入、FIFO和/或读取预取FIFO以提高系统性能。在里面在耦合模式下，FIFO被旁路，VMEbus事务直接耦合到PCI总线（即，VMEbus上的传输只有在完成后才能完成在PCI总线上完成）。

增强的总线错误处理-对宇宙芯片总线错误处理的增强提供了特征。提供了锁存器和寄存器允许SBC读取导致故障的VMEbus地址所有模式下的总线错误。宇宙芯片的支持是有限的到解耦模式。

支持总线周期超时和总线错误断言提供。该板可以被配置为断言总线错误时，不管其作为系统控制器的状态如何。这个Universe芯片仅当它是系统控制器时才断言总线错误。此外，该板可配置为断言中断在总线周期超时时。

G2010 A 10.4ST Each window can be programmed to operate in coupled or decoupled mode. Windows in decoupling mode utilize write, FIFO, and/or read prefetch FIOs to improve system performance. In coupling mode, the FIFO is bypassed and the VMEbus transaction is coupled directly to the PCI bus (i.e., the transfer on the VMEbus is completed only after completion on the PCI bus).

Enhanced Bus error handling - Enhancements to Cosmic chip bus error handling provide features. Latches and registers are provided to allow the SBC to read bus errors that cause failures in VMEbus addresses in all modes. Cosmic chip support is limited to the decoupling mode.

Support for bus cycle timeouts and bus error assertions is provided. The board can be configured to assert bus errors regardless of its status as a system controller. This Universe chip asserts a bus error only if it is the system controller. In addition, the board can be configured to assert interrupts when the bus cycle times out.
