DSSB140 48980001-P引导优先级由堆栈顺序决定，顶部的优先级最高优先级最低。可以通过突出显示设备来修改顺序并且，使用<+>或<->键，将其移动到堆栈中所需的顺序。设备可以通过突出显示特定设备并按Shift 1来禁用引导。<回车>展开或折叠设备，旁边带有+或-符号。

本附录为用户提供了开发定制软件所需的信息VMIVME-7698的应用程序。VMIVME-7698上的CPU板在BIOS无法删除；它必须在初始引导周期中使用。习惯应用程序，例如修改后的操作系统，只能开始运行BIOS完成CPU初始化后。

VMIVME-7698将允许用户可以保持当前BIOS配置，也可以将此配置更改为更特定于用户，但此更改只能在初始BIOS之后完成引导周期已完成。第109页图D-1中的框图说明了VMIVME-7698强调输入/输出功能，包括PCI到VMEbus桥。功能块左上角的带圆圈数字引用功能块编程所需的适当数据手册。VMIVME-7698上有两个用户必须熟悉的区域覆盖初始BIOS配置。其中包括设备地址和设备中断。本附录审查了这些地址和中断的详细信息，并提供了板上使用的单个设备的参考列表。

DSSB140 48980001-P The boot priority is determined by the stack order, with the highest priority at the top and the lowest priority. The order can be modified by highlighting the devices and, using the <+> or <-> keys, moving them into the desired order in the stack. Devices can disable booting by highlighting a specific device and pressing Shift 1. < Enter > Expand or collapse the device with a + or - symbol next to it.

This appendix provides users with the information needed to develop custom software for VMIVME-7698 applications. The CPU board on VMIVME-7698 cannot be deleted in the BIOS. It must be used during the initial boot cycle. Custom applications, such as modified operating systems, can only start running the BIOS after CPU initialization.

VMIVME-7698 will allow the user to either keep the current BIOS configuration or change this configuration to be more user-specific, but this change can only be made after the initial BIOS boot cycle has completed. The block diagram in Figure D-1 on page 109 illustrates that the VMIVME-7698 emphasizes input/output functionality, including the PCI to VMEbus bridge. The circled number in the upper left corner of the function block refers to the appropriate data book required for the function block programming. There are two areas on the VMIVME-7698 that users must be familiar with covering the initial BIOS configuration. These include device addresses and device interrupts. This appendix reviews the details of these addresses and interrupts and provides a reference list of the individual devices used on the board.
