AO820 3BSE008546R1 S800 I/O 模拟量输出模块

AO820 3BSE008546R1 S800 I/O 模拟量输出模块

AO820 3BSE008546R1是ABB制造的模拟输出模块，用于Advant Controller 400系列的S800 I/O系统。它设计用于生成模拟电压或电流信号，以控制工业自动化应用中的执行器、阀门和其他设备。

主要特点：

4 个模拟输出通道：AO820 模块提供 4 个独立的模拟输出通道，每个通道能够生成 0-20 mA 或 ±10 V 信号，分辨率为 12 位，可实现精确控制。

高精度：该模块提供高精度，确保以最小的误差精确生成模拟信号。

宽输出范围：该模块支持 0-20 mA 或 ±10 V 的宽输出范围，适用于各种控制应用。

隔离：该模块在通道和系统接地之间具有电气隔离功能，可防止噪声和接地环路。

短路保护：该模块提供短路保护，以防止意外或故意短路。

技术规格：

输出类型：模拟电压或电流（0-20 mA 或 ±10 V）

输出范围：0-20 mA 或 ±10 V（每个通道可选）

精度：满量程的±0.1%

分辨率：12 位

更新速率：高达 250 ms

工作温度：-25°C 至 70°C（-13°F 至 158°F）

储存温度：-40°C 至 85°C（-40°F 至 185°F）

湿度：5% 至 95% RH（非冷凝）

振动：0.5 g rms，57 至 500 Hz

冲击：5 g，22 ms 半正弦波

应用：

AO820 3BSE008546R1模拟量输出模块常用于各种工业自动化应用，包括：

过程控制：控制阀门、执行器和其他设备，以调节石油和天然气、化工和发电等行业的温度、压力、流量和液位等过程变量。

位置控制：在机器人、机床和包装机械等应用中控制电机、执行器和其他线性或旋转设备的位置。

速度控制：在输送机、泵和风扇等应用中控制电机、驱动器和其他旋转设备的速度。

测试与测量：生成模拟信号，用于传感器、仪器和其他电子设备的测试和校准。

实验室自动化：在化学分析、药物发现和材料测试等应用中控制和监测实验室设备。

总体而言，AO820 3BSE008546R1模拟输出模块是工业自动化应用的多功能可靠组件，为各种工业过程中的执行器、阀门和其他设备的控制提供精确和准确的模拟信号生成、高精度和宽输出范围。

AO820 3BSE008546R1 S800 I/O 模拟量输出模块

The AO820 3BSE008546R1 is an analog output module manufactured by ABB for the S800 I/O system in the Advant Controller 400 series. It is designed to generate analog voltage or current signals to control actuators, valves and other devices in industrial automation applications.

Main features:

4 analog output channels: The AO820 module provides 4 independent analog output channels, each capable of generating 0-20 mA or ±10 V signals with a resolution of 12 bits for precise control.

High precision: This module provides high precision, ensuring that analog signals are precisely generated with minimal error.

Wide output range: The module supports a wide output range of 0-20 mA or ±10 V for a variety of control applications.

Isolation: The module has electrical isolation between the channel and system grounding to prevent noise and grounding loops.

Short circuit protection: This module provides short circuit protection to prevent accidental or intentional short circuits.

Technical specifications:

Output type: Analog voltage or current (0-20 mA or ±10 V)

Output range: 0-20 mA or ±10 V (optional per channel)

Accuracy: ±0.1% of full scale

Resolution: 12 bits

Update rate: up to 250 ms

Operating temperature: -25°C to 70°C (-13°F to 158°F)

Storage temperature: -40°C to 85°C (-40°F to 185°F)

Humidity: 5% to 95% RH (non-condensing)

Vibration: 0.5 g rms, 57 to 500 Hz

Shock: 5 g, 22 ms half sine wave

Applications:

AO820 3BSE008546R1 Analog output modules are commonly used in a variety of industrial automation applications, including:

Process control: Controls valves, actuators, and other equipment to regulate process variables such as temperature, pressure, flow, and level in industries such as oil and gas, chemicals, and power generation.

Position control: Controlling the position of motors, actuators and other linear or rotating devices in applications such as robotics, machine tools and packaging machinery.

Speed control: Control the speed of motors, drives and other rotating equipment in applications such as conveyors, pumps and fans.

Test and measurement: Generates analog signals for testing and calibration of sensors, instruments and other electronic devices.

Laboratory automation: Control and monitoring of laboratory equipment in applications such as chemical analysis, drug discovery and material testing.

Overall, the AO820 3BSE008546R1 analog output module is a versatile and reliable component for industrial automation applications, providing precise and accurate analog signal generation, high precision and wide output range for the control of actuators, valves and other equipment in a variety of industrial processes.
