AI835 3BSE008520R1 S800 I/O 模拟量输入模块

AI835 3BSE008520R1 S800 I/O 模拟量输入模块

AI835 3BSE008520R1 S800 I/O模拟量输入模块是ABB生产的一款高性能工业自动化产品，用于S800 I/O系统。它设计用于接收和处理来自各种工业传感器和传感器的模拟信号，为过程控制、监控和报警应用提供有价值的数据。

主要特点：

高精度：AI835 模块提供高精度，确保以最小的误差精确测量模拟信号。

宽输入范围：该模块支持各种模拟信号类型的宽输入范围，包括热电偶、RTD、电压和电流。

多渠道支持：该模块提供 8 个输入通道，可同时处理来自多个传感器或传感器的信号。

隔离：该模块在通道和系统接地之间具有电气隔离功能，可防止噪声和接地环路。

技术规格：

输入类型：热电偶、RTD、电压、电流（取决于具体型号）

输入范围：热电偶：J、K、E、T、R、S、B、C、N;RTD：Pt100、Pt1000、Cu50;电压：-10 V 至 +10 V;电流：4 mA 至 20 mA

精度：满量程的±0.1%

分辨率：15位

更新速率：高达 250 ms

工作温度：-25°C 至 70°C（-13°F 至 158°F）

储存温度：-40°C 至 85°C（-40°F 至 185°F）

湿度：5% 至 95% RH（非冷凝）

振动：0.5 g rms，57 至 500 Hz

冲击：5 g，22 ms 半正弦波

应用：

AI835 3BSE008520R1 S800 I/O 模拟量输入模块常用于各种工业自动化应用，包括：

过程控制：监测和控制石油和天然气、化工、食品和饮料等行业的温度、压力、流量和液位等过程变量。

测温：在炉子控制、热处理和热过程监控等应用中使用热电偶和 RTD 精确测量温度。

状态监测：通过跟踪振动、温度和其他参数来监控机器的健康和状况，以检测潜在故障并防止故障。

报警系统：根据模拟信号阈值触发警报，以提醒操作员注意异常情况或潜在危险。

数据采集：从传感器和传感器收集模拟数据，用于分析、可视化和历史趋势分析。

总体而言，AI835 3BSE008520R1 S800 I/O 模拟输入模块是适用于工业自动化应用的多功能且可靠的组件，可为过程控制、温度测量、监控、报警和数据采集应用提供准确可靠的模拟信号采集。

AI835 3BSE008520R1 S800 I/O 模拟量输入模块

The AI835 3BSE008520R1 S800 I/O Analog Input module is a high-performance industrial automation product produced by ABB for the S800 I/O system. It is designed to receive and process analog signals from a variety of industrial sensors and sensors, providing valuable data for process control, monitoring and alarm applications.

Main features:

High accuracy: The AI835 module provides high precision, ensuring accurate measurement of analog signals with minimal error.

Wide input range: The module supports a wide input range for various analog signal types, including thermocouples, RTDS, voltages, and currents.

Multi-channel support: The module provides 8 input channels to process signals from multiple sensors or sensors simultaneously.

Isolation: The module has electrical isolation between the channel and system grounding to prevent noise and grounding loops.

Technical specifications:

Input type: Thermocouple, RTD, voltage, current (depending on the model)

Input range: Thermocouple: J, K, E, T, R, S, B, C, N; RTD: Pt100, Pt1000, Cu50; Voltage: -10 V to +10 V; Current: 4 mA to 20 mA

Accuracy: ±0.1% of full scale

Resolution: 15 bits

Update rate: up to 250 ms

Operating temperature: -25°C to 70°C (-13°F to 158°F)

Storage temperature: -40°C to 85°C (-40°F to 185°F)

Humidity: 5% to 95% RH (non-condensing)

Vibration: 0.5 g rms, 57 to 500 Hz

Shock: 5 g, 22 ms half sine wave

Applications:

The AI835 3BSE008520R1 S800 I/O analog input modules are commonly used in a variety of industrial automation applications, including:

Process control: Monitor and control process variables such as temperature, pressure, flow and level in the oil and gas, chemical, food and beverage industries.

Temperature measurement: Use thermocouples and RTDS to accurately measure temperature in applications such as furnace control, heat treatment and thermal process monitoring.

Condition monitoring: Monitors machine health and condition by tracking vibration, temperature, and other parameters to detect potential failures and prevent them.

Alarm system: Triggers alarms based on analog signal thresholds to alert operators to abnormal conditions or potential hazards.

Data Acquisition: Collect analog data from sensors and sensors for analysis, visualization, and historical trend analysis.

Overall, the AI835 3BSE008520R1 S800 I/O analog input module is a versatile and reliable component for industrial automation applications, providing accurate and reliable analog signal acquisition for process control, temperature measurement, monitoring, alarm and data acquisition applications.

AI835 3BSE008520R1 S800 I/O 模拟量输入模块
