DSTA133 模拟板连接单元

DSTA133 模拟板连接单元

DSTA133模拟板连接单元是ABB Ability System 800xA分布式控制系统（DCS）中的关键组件。 它用作模拟输入和输出 （I/O） 模块和 DCS 控制器之间的多功能接口，可实现无缝数据采集、处理和控制。

主要特点：

模块化设计：DSTA133采用模块化设计，可允许灵活配置各种模拟 I/O 模块，以满足特定的应用要求。

高分辨率数据采集：该装置支持从模拟传感器采集高分辨率数据，确保准确可靠地表示真实过程参数。

模拟输出控制：该DSTA133可通过其模拟输出通道精确控制模拟执行器和设备。

技术规格：

模拟输入通道数：最多 32 个（取决于 I/O 模块配置）

模拟输出通道数：最多 16 个（取决于 I/O 模块配置）

模拟输入分辨率：高达 16 位

模拟输出分辨率：高达 16 位

信号调理：放大、滤波、隔离

故障检测：过压、过流、开路

DSTA133 模拟板连接单元

The DSTA133 analog board connection unit is a key component in the ABB Ability System 800xA Distributed control System (DCS). It serves as a multifunctional interface between analog input and output (I/O) modules and DCS controllers for seamless data acquisition, processing and control.

Main features:

Modular design: The modular design of the DSTA133 allows for flexible configuration of various analog I/O modules to meet specific application requirements.

High-resolution data acquisition: The device supports the acquisition of high-resolution data from analog sensors, ensuring accurate and reliable representation of real process parameters.

Analog output control: The DSTA133 provides precise control of analog actuators and devices through its analog output channel.

Technical specifications:

Number of analog input channels: up to 32 (depending on I/O module configuration)

Number of analog output channels: up to 16 (depending on I/O module configuration)

Analog input resolution: up to 16 bits

Analog output resolution: up to 16 bits

Signal conditioning: amplification, filtering, isolation

Fault detection: overvoltage, overcurrent, open circuit

DSTA133 模拟板连接单元
