RAIO-01 直流调速器

RAIO-01 直流调速器

ABB RAIO-01 不是直流电机控制器。它是用于ABB变频器的模拟I/O扩展模块。

它提供两个双极性电流 （0[4]...20 mA）或电压（0[2]...10 V 或 0...2 V） 输入和两个单极性电流 （0[4]...20 mA） 输出，具有 12 位分辨率。模拟输入和输出彼此之间以及与电源电气隔离。它安装在驱动器 RMIO 板上的可选插槽上，或安装在外部的 AIMA-01 I/O 模块适配器上。它具有 IP 20 防护等级。

主要特点：

模拟 I/O 通道：2 个双极性电流/电压输入和 2 个单极性电流输出

分辨率：12 位

隔离：模拟输入/输出和电源之间的电气隔离

安装：安装在驱动器 RMIO 板上的可选插槽上，或安装在外部的 AIMA-01 I/O 模块适配器上

防护等级：IP 20 防护等级

应用：

RAIO-01 模拟量 I/O 扩展模块常用于需要精确模拟信号采集和控制的各种工业自动化应用，例如：

过程控制：监测和控制工业过程中的过程变量，如温度、压力、流量和液位。

机器控制：与传感器和执行器连接，用于精确控制机器运动和操作。

数据采集：从传感器和传感器收集模拟数据，用于监测和分析。

兼容性：

RAIO-01 兼容 ABB 变频器，例如 ACS500、ACS800 和 ACS1000 系列，这些变频器具有 RMIO 板或支持 AIMA-01 I/O 模块适配器。

总体而言，ABB RAIO-01是一款多功能且可靠的模拟I/O扩展模块，可为各种工业自动化应用提供精确的信号采集和控制功能。

RAIO-01 直流调速器

ABB RAIO-01 is not a DC motor controller. It is an analog I/O expansion module for ABB converters.

It provides two bipolar currents (0[4]... 20 mA) or voltage (0[2]... 10 V or 0... 2 V) input and two unipolar currents (0[4]... 20 mA) output with 12-bit resolution. Analog inputs and outputs are electrically isolated from each other and from the power supply. It is installed in an optional slot on the drive RMIO board, or on an external AIMA-01 I/O module adapter. It has IP 20 protection level.

Main features:

Analog I/O channels: 2 bipolar current/voltage inputs and 2 unipolar current outputs

Resolution: 12 bits

Isolation: Electrical isolation between analog input/output and power supply

Mount: Mount in an optional slot on the drive RMIO board, or mount on an external AIMA-01 I/O module adapter

Protection: IP 20 Protection level

Applications:

The RAIO-01 Analog I/O expansion module is commonly used in a variety of industrial automation applications that require accurate analog signal acquisition and control, such as:

Process control: Monitoring and controlling process variables in industrial processes such as temperature, pressure, flow and level.

Machine control: Connected to sensors and actuators for precise control of machine movement and operation.

Data acquisition: Analog data is collected from sensors and sensors for monitoring and analysis.

Compatibility:

The RAIO-01 is compatible with ABB drives, such as the ACS500, ACS800 and ACS1000 series, which have RMIO boards or support AIMA-01 I/O module adapters.

Overall, the ABB RAIO-01 is a versatile and reliable analog I/O expansion module that provides precise signal acquisition and control functions for a variety of industrial automation applications.
