2711-K6C5 是一款 PanelView 600 标准操作终端

目录号为 2711-K6C5 的 PanelView Standard 操作终端是 Allen-Bradley 的 PanelView 600 可视化组件。该操作终端通常被称为人机界面 （HMI），其主要目的是通过 HMI 中嵌入的功能组合为过程操作员提供实时监控和过程接口。

过程可视化通过 5 英寸彩色图形显示器实现，其中可以实现带有颜色编码信息的动画。这款彩色屏幕的功能显示面积为 115 x 86 毫米（4.54 x 3.4 英寸）。屏幕分辨率为 320 x 234 像素。屏幕与内部背光配对，可现场更换，预计运行时间可达 50,000 小时。

操作员控制和界面由嵌入式键盘提供，该键盘由十 （10） 个功能键、导航键和数字键组成。每个键都执行单独的功能，功能键能够接受本地和全局分配。这些按键预计可执行多达 100 万次驱动，并且可以与功能键图例插件一起安装。

2711-K6C5 具有 DH485 通信端口，兼容 Allen-Bradley 的不同可编程逻辑控制器 （PLC） 产品，例如 SLC 500、MicroLogix、CompactLogix 和 ControlLogix 处理器。它还与第三方控制器和设备兼容，以实现过程可视化和集中监控。

2711-K6C5 是小型机器和工艺的理想选择。它具有内置的 240KB 非易失性存储器和 190KB 运行时应用程序存储器。它的额定电源输入范围为 85-264V AC，频率为 47-63 Hz。

这款 PV 600 具有生动的 5 英寸。彩色显示。用户能够使用键盘控制HMI以输入信息和数据。

本机使用 85-264 VAC 电源供电。本机具有以下内部存储器：240 KB 非易失性和 190KB 运行时存储器。2711-K6C5 PanelView 的可更换背光为 2711-NL3（用于 A 系列和 B 系列设备），以及 2711-NL5（用于 C 系列设备）。

RS-232（DH-485 协议）终端使用 DH-485 协议连接到 MicroLogix 和 SLC 500 控制器。点对点配置对高优先级数据使用单独的连接。他们还可以使用 AIC+ 模块连接到 DH-485 网络。

此过程也可以通过 RS-232 打印机端口、标准 RS-232/DH-485 端口或 PC 存储卡（如 2711-NM232）完成。

2711-K6C5 是一款 PanelView 600 标准操作终端

The PanelView Standard Operating terminal, catalog number 2711-K6C5, is Allen-Bradley's PanelView 600 visual component. This operating terminal is often referred to as a Human machine interface (HMI) and its main purpose is to provide real-time monitoring and process interfaces to process operators through a combination of functions embedded in the HMI.

Process visualization is achieved through a 5-inch color graphic display, where animations with color-coded information can be implemented. The color screen features a display area of 115 x 86 mm (4.54 x 3.4 inches). The screen resolution is 320 x 234 pixels. The screen is paired with an internal backlight and can be replaced on site, with an estimated operating time of up to 50,000 hours.

Operator control and interface are provided by an embedded keyboard consisting of ten (10) function keys, navigation keys, and number keys. Each key performs a separate function, and function keys are capable of accepting both local and global assignments. These keys are expected to perform up to 1 million drives and can be installed with the function key legend plug-in.

The 2711-K6C5 has a DH485 communication port and is compatible with Allen-Bradley's different programmable logic controller (PLC) products, such as the SLC 500, MicroLogix, CompactLogix, and ControlLogix processors. It is also compatible with third-party controllers and devices for process visualization and centralized monitoring.

The 2711-K6C5 is ideal for small machines and processes. It has 240KB of built-in non-volatile memory and 190KB of runtime application memory. It has a rated power input range of 85-264V AC and a frequency of 47-63 Hz.

This PV 600 has a vivid 5-inch. Display in color. Users can use the keyboard to control the HMI to enter information and data.

This unit uses 85-264 VAC power supply. The unit has the following internal memory: 240 KB non-volatile and 190KB runtime memory. The 2711-K6C5 PanelView has replaceable backlights of 2711-NL3 (for Series A and B devices) and 2711-NL5 (for Series C devices).

RS-232 (DH-485 protocol) terminals use the DH-485 protocol to connect to MicroLogix and SLC 500 controllers. A peer-to-peer configuration uses separate connections for high-priority data. They can also connect to DH-485 networks using AIC+ modules.

This process can also be done via an RS-232 printer port, a standard RS-232/DH-485 port, or a PC memory card such as 2711-NM232.
