1769-L32CA 1769 控制器产品线中的模块化

1769-L32CA 1769 控制器产品线中的模块化

1769-L32C 是由 Allen-Bradley/Rockwell Automation 制造的 CompactLogix 控制器。该控制器非常重要，因为每个 ControlNet 网络都需要至少一个类似的模块，该模块能够在启动过程后存储参数和网络配置数据。1769-L32C 可以存储数据，同时作为备份工作。所有这些操作都是自动的。Allen-Bradley 1769-L32C CompactLogix 控制器带有不同的通信端口，即通道 232 上的 RS-4、NAP 和 ControlNet 端口。它还使用 750 KB 的内存，并具有 16 个 I/O 模块。Allen-Bradley 1769-L32C CompactLogix 控制器具有 3 个 I/O bank，在 650 V DC 时具有 5 毫安的背板电流，在 40 V DC 时具有 24 毫安的背板电流。1769-L32C 逻辑模块的功耗为 4.21 瓦。Allen-Bradley 1769-L32C CompactLogix 控制器的电池只能用 Allen-Bradley 1769-BA 电池更换。

Allen-Bradley 1769-L32C CompactLogix 控制器的工作温度范围为 0 至 60 摄氏度，相对湿度为 5 至 95%。为了延长模块的使用寿命，保持合适的温度非常重要。像这样的模块很容易被腐蚀和损坏。Allen-Bradley 1769-L32C CompactLogix 控制器提供状态指示器，显示模块的当前状态。这些指示灯在亮起时可以稳定、交替或闪烁。这 3 种类型的灯具有不同的含义，是理解和解决控制器可能遇到的不同问题的好方法。通过这些状态指示灯可以显示断电、机架上的模块放错位置或主要和次要故障等情况。Allen-Bradley 1769-L32C CompactLogix 控制器的重量约为 0.32 千克。1769-L32C 逻辑模块支持 100 个连接，可以在 CompactFlash 存储器中保存和恢复用户应用程序。

1769-L32CA 1769 控制器产品线中的模块化

The 1769-L32C is a CompactLogix controller manufactured by Allen-Bradley/Rockwell Automation. This controller is important because every ControlNet network requires at least one similar module that is capable of storing parameters and network configuration data after the startup process. The 1769-L32C can store data and work as a backup. All of these operations are automatic. The Allen-Bradley 1769-L32C CompactLogix controller comes with different communication ports, namely RS-4, NAP, and ControlNet ports on channel 232. It also uses 750 KB of memory and has 16 I/O modules. The Allen-Bradley 1769-L32C CompactLogix controller features 3 I/O banks with 5 mA backplane current at 650 V DC and 24 mA backplane current at 40 V DC. The 1769-L32C logic module has a power consumption of 4.21 watts. The battery of the Allen-Bradley 1769-L32C CompactLogix controller can only be replaced with an Allen-Bradley 1769-BA battery.

The Allen-Bradley 1769-L32C CompactLogix controller operates in a temperature range of 0 to 60 degrees Celsius and relative humidity of 5 to 95%. In order to extend the service life of the module, it is very important to maintain the right temperature. Modules like this are easily corroded and damaged. The Allen-Bradley 1769-L32C CompactLogix controller provides a status indicator that shows the current status of the module. These lights can be steady, alternating, or blinking when on. These 3 types of lamps have different meanings and are a good way to understand and solve the different problems that your controller may encounter. These status indicators can indicate power outages, misplaced modules on the rack, or major and minor faults. The Allen-Bradley 1769-L32C CompactLogix controller weighs approximately 0.32 kg. The 1769-L32C logic module supports 100 connections and can save and restore user applications in CompactFlash memory.
