1747-L541 SLC 500 模块化硬件控制器模块

1747-L541 SLC 500 模块化硬件控制器模块

Allen-Bradley 1747-L541 是 SLC 5/04 处理器，是 SLC 500 系列的一部分，该系列还包括 1747-L541、L542 和 L543 控制器。它是一款高性能处理器，具有更快的通信速度和更短的程序执行时间。SLC 5/04 具有 16K、32K 或 64K 字的内存，最多可控制 4096 个输入和输出点。在通信方面，1747-L541 具有内置的 DH+ 通道，支持扩展的消息传递功能和高速通信。它还具有一个 RS-232 通道，用于支持 DF1 无线电调制解调器、DH-485、ASCII 和 Modbus RTU 通信。对于编程，它包括高级数学指令和各种附加指令。它还支持远程 I/O、DeviceNet 直通和间接寻址。

1747-L541 的每个关键字的典型程序扫描时间为 0.9 毫秒，典型的 I/O 扫描时间为 0.225 毫秒。它需要 1 V DC 时 5 A 的背板电流负载和 200 V DC 时 24 mA 的背板电流负载。它具有 1 毫秒可选定时中断 （STI） 和 0.5 毫秒离散输入中断 （DII）。对于程序和数据表存储，它使用具有 1747 KB 内存的 13-M64 闪存存储设备。SLC 5/04 在前面板上包括一个 3 位钥匙开关，用于选择运行、远程或程序模式。1747-L541 SLC 504 具有 RUN、FLT、BATT、FORCE、DH+ 和 RS-232 LED 状态指示灯，用于故障排除和诊断。SLC 500 系列处理器采用简单、经济高效的设计，在 HVAC 控制、SCADA 和物料搬运等应用中具有良好的安装经验。

Allen-Bradley 1747-L541 是一款 SLC 5/04 控制器，具有集成的 16 KB 用户内存，设计用于处理多达 4096 个输入和输出。该控制器属于模块化 SLC 500 可编程逻辑控制器 （PLC）。

1747-L541 非常适合在中型应用中使用，因为该控制器能够使用 CPU 机架上的通信适配器和 IO 机架上的通信扫描仪来实现分布式 IO 应用。RS232 通信端口可配置为 DF1 和 DH485 点对点拓扑，而 DH+ 通信支持远距离和多点拓扑。

或者，RS232 通信端口也可以与 1761-NET-AIC 一起使用，以允许串行端口连接到多点网络。通信端口的默认设置是无握手、19.2 Kbaud、CRC 错误检查、重复数据包、检测开启且无奇偶校验（RS232 端口）和 57.6 Kbaud，Data Highway Plus （DH+） 的节点地址 = 1。

1747-L541 控制器需要一个 SLC 500 机架来安装和连接到电子背板。还需要一个系统电源，以便通过电子背板为处理器的内部电路供电。

该控制器已通过 UL 认证，符合美国和加拿大安全标准，符合 CE 标准并带有 C-Tick 标志。

1747-L541 SLC 500 模块化硬件控制器模块

The Allen-Bradley 1747-L541 is an SLC 5/04 processor, part of the SLC 500 family, which also includes the 1747-L541, L542, and L543 controllers. It is a high-performance processor with faster communication speeds and shorter program execution times. The SLC 5/04 has 16K, 32K or 64K words of memory and can control up to 4096 input and output points. In terms of communications, the 1747-L541 has a built-in DH+ channel that supports extended messaging capabilities and high-speed communications. It also has an RS-232 channel to support DF1 radio modem, DH-485, ASCII, and Modbus RTU communications. For programming, it includes advanced mathematical instructions and various additional instructions. It also supports remote I/O, DeviceNet pass-through, and indirect addressing.

The typical program scan time for each keyword of 1747-L541 is 0.9 ms, and the typical I/O scan time is 0.225 ms. It requires A backplane current load of 5 A at 1 V DC and 24 mA at 200 V DC. It has a 1 ms selectable time interrupt (STI) and 0.5 ms discrete input interrupt (DII). For program and data table storage, it uses a 13-M64 flash storage device with 1747 KB of memory. The SLC 5/04 includes a 3-digit key switch on the front panel for selecting Run, remote, or program modes. The 1747-L541 SLC 504 features RUN, FLT, BATT, FORCE, DH+, and RS-232 LED status indicators for troubleshooting and diagnosis. The SLC 500 series processors feature a simple, cost-effective design with proven installation experience in HVAC control, SCADA, and material handling applications.

The Allen-Bradley 1747-L541 is an SLC 5/04 controller with an integrated 16 KB of user memory designed to handle up to 4096 inputs and outputs. The controller is a modular SLC 500 programmable logic controller (PLC).

The 1747-L541 is ideal for use in mid-sized applications, as the controller is able to implement distributed IO applications using a communication adapter on the CPU rack and a communication scanner on the IO rack. The RS232 communication port can be configured for DF1 and DH485 point-to-point topologies, while DH+ communication supports long-distance and multipoint topologies.

Alternatively, the RS232 communication port can also be used with the 1761-NET-AIC to allow a serial port to connect to a multipoint network. The default Settings for communication ports are No handshake, 19.2 Kbaud, CRC error check, Duplicate packet, detection enabled and parity parity (RS232 port) and 57.6 Kbaud, Data Highway Plus (DH+) node address = 1.

The 1747-L541 controller requires an SLC 500 rack to mount and connect to the electronic backplane. A system power supply is also required to power the processor's internal circuitry through an electronic backplane.

The controller has passed the UL certification, meets the U.S. and Canadian safety standards, meets the CE standard and carries a C-Tick mark.
