Allen-Bradley 1747-ASB 是远程 I/O 适配器模块，是 SLC 500 系统的一部分。它通过远程 I/O 在 SLC 或 PLC 扫描仪与各种 1746 I/O 模块之间建立通信链路。远程 I/O 链路由一个主设备（即 SLC 或 PLC 扫描仪）和一个或多个作为适配器的从设备组成。SLC 或 PLC 映像表直接从其机箱获取 I/O 模块映像映射。对于图像映射，它支持离散传输和块传输。1747-ASB 支持 1/2 插槽、1 插槽和 2 插槽寻址，具有高效的镜像利用率。它安装在带有 SLC 500 处理器的机箱中，并扫描机箱中的 I/O。

1747-ASB 模块在 375V 时具有 5 mA 背板电流，在 0V 时具有 24 mA 背板电流。它的最小和最大散热为 1.875 W。它可以在最远 3040 米的距离内传输 I/O 数据，并支持 57.6K、115.2K 和 230.4K 波特率。它允许用户选择最多 32 个逻辑组的映像大小，并控制多达 30 个机箱插槽。1747-ASB 还为多达 32 个适配器提供非易失性存储器和扩展节点功能。接线时，必须使用 Belden 9463 或类似类别的电缆，并且不需要任何用户编程。它使用 6 针凤凰连接器在远程 I/O 链路和处理器之间进行连接。1747-ASB 模块支持所有 SLC 501 I/O 模块，如基本模块、电阻模块、高速计数器模块等。对于故障排除和操作，它有三个 7 段显示器，具有显示操作状态和错误的增强功能。1747-ASB 旨在用于工业环境，并提供 NEMA 标准抗噪性。

1747- ASB 是属于 SLC 500 自动化平台的远程 IO 适配器。此 IO 适配器与 I/O 扫描器模块、接口卡和网关通信，以建立远程 IO 连接。

对于 PLC 应用，该模块的主要目的是通过远程 I/O 网络实现分布式 IO 应用。与 SLC 扩展总线相比，该扩展的电缆长度有限，SLC 机箱扩展非常有限。使用1747-ASB，最多可使用32个带有1747 RIO扫描仪的SLC机箱，适用距离为762米或2500英尺（230.4 KBaud），1524米或5000英尺（115.2 KBaud）和3048米或10,000英尺（57.6 KBaud）。该适配器的控制能力最多为30个，此30插槽限制可以分段到不同的机箱或机架，每个机架都安装了RIO扫描仪和电源。

除了与远程 IO 扫描仪通信外，该模块还可用于与直接安装在个人计算机上的 Allen-Bradley 通信卡进行通信。这实现了远程编程和配置功能，以及通过监控和数据采集 （SCADA） 进行远程控制。或者，Allen-Bradley 人机界面 （HMI） （如 PanelView 产品）能够添加远程 I/O 适配器，使 HMI 能够像 SCADA 系统一样控制过程。

该远程 I/O 适配器还支持与 Allen-Bradley encompass 合作伙伴产品以及第三方网关和转换器的通信，以实现与其他自动化产品的第三方通信。
