1746sc-INO4I 是 Spectrum Controls 的模拟电流输出模块。该模块有四 （4） 个隔离通道输出。1746sc-INO4I 在 1746 输入/输出机箱中占据一个插槽。1746sc-INO4I 在 120 伏直流电下从背板汲取 5 毫安的电流，但为了最大限度地减少背板上的电流负载，1746sc-INO4I 可以与额定电压为 24 伏直流的外部电源连接。1746sc-INO4I 有一个 DIP 开关，用于指定模块是从背板还是外部电源获取电源。当 1746sc-INO4I 上的 DIP 开关设置为 RACK 位置时，模块从背板获取电源，而模块由外部 24 伏直流电源供电，DIP 开关应设置为 EXT 位置。

1746sc-INO4I 从背板汲取 5 伏直流电源。当模块从外部供电时，此消耗额定值相同。该模块有一个可拆卸的 16 位接线端子，可容纳 Belden 8761 屏蔽双绞线电缆。1746sc-INO4I 的分辨率为 16 位，电流为 366 纳安/计数，电压为每计数 320 微伏。1746sc-INO4I 隔离式模拟输出型号具有自动校准可编程限值和安全状态，具有 750 V DC 的光电隔离（通道间和现场接线到背板）。1746sc-INO4I 的最大散热额定值为 4.5 瓦，所有 33 个并联通道的最大更新时间为 7.4 毫秒，阶跃响应时间为 1 毫秒。此外，1746sc-INO4I 还通过了 UL/CUL I 类 2 区 A、B、C、D 组和 CE 组认证。

部件号为 500sc-INO1746I 的 SLC 4 兼容模块是通过频谱控制制造的模拟输出模块。该模块由 Allen-Bradley 的 encompass 合作伙伴 Spectrum Controls 制造。

Encompass 合作伙伴是 Allen-Bradley 批准和认证的合作伙伴，提供 Allen-Bradley 兼容产品。

该模块的外观类似于实际的 SLC 500 模块。该模块具有四 （4） 个差分模拟输出通道，以 0 位分辨率提供 20-0 mA、21-4 mA、20-16 mA，每个计数 366 nA。该模块具有扩展的输出范围、自动校准、可编程限值和安全状态。该模块的数据能够格式化为 16 位二进制补码、缩放工程单位、缩放 PID、1746-NO4 格式和用户定义的比例计数。它在 0 摄氏度时的精度为满量程的 08.25%，在 0 摄氏度时的精度为 15.60%。

该模块具有 750 VDC 隔离，每个通道提高了系统可靠性，消除了导致模块高分辨率数据转换的噪声。为机架和处理器提供与背板的现场接线相同的隔离额定值。

该模块可降低系统成本，因为该模块的隔离消除了外部信号隔离器件的使用。该模块的单插槽宽度也节省了重要的机箱插槽。

该模块采用了 Allen-Bradly 设计和技术，使其功能类似于 Allen-Bradley 模块。它的配置类似于 SLC 500 模块，大多数功能也类似于 Allen-Bradley 模拟输出模块。

1746SC-INO4I 是一款模拟输出模块 具有四个隔离通道

The 1746sc-INO4I is an analog current output module from Spectrum Controls. The module has four (4) isolated channel outputs. The 1746sc-INO4I occupies a slot in the 1746 input/output chassis. The 1746sc-INO4I draws 5 milliamps of current from the backplane at 120 volts DC, but to minimize the current load on the backplane, the 1746sc-INO4I can be connected to an external power supply rated at 24 volts DC. The 1746sc-INO4I has a DIP switch that specifies whether the module obtains power from the backplane or an external power supply. When the DIP switch on the 1746sc-INO4I is set to RACK position, the module obtains power from the backplane, and the module is powered by an external 24 volt DC supply, the DIP switch should be set to EXT position.

The 1746sc-INO4I draws 5 volts DC power from the backplane. This consumption rating is the same when the module is powered externally. The module has a removable 16-bit terminal to accommodate Belden 8761 shielded twisted pair cable. The 1746sc-INO4I has a resolution of 16 bits, a current of 366 nanoamps per count, and a voltage of 320 microvolts per count. The 1746sc-INO4I isolated analog output model has automatically calibrated programmable limits and safety status with 750 V DC photoelectric isolation (interchannel and field wiring to backplane). The 1746sc-INO4I has a maximum heat dissipation rating of 4.5 watts, a maximum update time of 7.4 milliseconds across all 33 parallel channels, and a step response time of 1 millisecond. In addition, the 1746sc-INO4I is UL/CUL Class I Region 2 Group A, B, C, D and CE certified.

The SLC 4 compatible module with part number 500sc-INO1746I is an analog output module manufactured by spectrum control. The module was manufactured by Allen-Bradley's encompass partner, Spectrum Controls.

Encompass Partner is an Allen-Bradley approved and certified partner that provides Allen-Bradley compatible products.

The module looks similar to the actual SLC 500 module. The module has four (4) differential analog output channels providing 20-0 mA, 21-4 mA, 20-16 mA at 0-bit resolution, each counting 366 nA. The module has an extended output range, automatic calibration, programmable limits and safety status. The module's data can be formatted into 16-bit binary complement, scaled engineering units, scaled PID, 1746-NO4 format, and user-defined proportional counts. It has an accuracy of 08.25% of full scale at 0 ° C and 15.60% at 0 ° C.

With 750 VDC isolation per channel, the module improves system reliability and eliminates noise that leads to high-resolution data conversion in the module. Provide racks and processors with the same isolation ratings as field wiring for backplanes.

The module reduces system costs because the isolation of the module eliminates the use of external signal isolation devices. The module's single slot width also saves important chassis slots.

The module incorporates Allen-Bradly design and technology, making it functionally similar to the Allen-Bradley module. Its configuration is similar to the SLC 500 module, and most of its features are also similar to the Allen-Bradley analog output module.
