Allen-Bradley 1746-OW16 是用于 SLC 500 产品系列的 Allen-Bradley 分立式输出模块。该模块是继电器输出模块，有时也称为干接点输出模块。

该模块非常适合用于存在混合电压类别的应用。电压类别，例如直流电压，范围为 5 -125 VDC 和 5 - 265 VA。它有两 （2） 个输入组，每组一 （1） 个公共端子。这些分组允许一组使用直流电压运行，而另一组使用交流电压运行。它也可以与直流电压或交流电压输入一起使用。使用此模块无需实现插入电路。

在 120VAC 下运行时，断路安培额定值为 15 A，而断路额定值为 1.5 A。对于 240VAC，接通电流额定值为 7.5 A，断路电流额定值为 0.75 A，交流操作的连续电流为 2.5 A。在 125 VDC 下工作时，接点额定值为 0.22 A，断开触点额定值为 1.2 A。在 125 VDC 时，连续电流为 1.0 A，在 2VDC 工作时为 0.24 A。建议为每个通道外部安装浪涌抑制装置。使用这些设备可以防止损坏模块，从而延长模块的使用寿命。

Allen-Bradley 1746-OW16 是 Allen-Bradley SLC 500 分立式输出模块中的一款。它用于该模块有十六 （16） 个继电器触点输出，两 （2） 组每个公共端有八 （8） 个点。

安装此模块需要不接触化学品，因为化学品可能会降低密封材料的密封性能。定期检查模块是否有化学损坏。

1746-OW16 有两个工作电压：5 - 125V DC 和 5 - 265V DC。在最大阻性负载下，它在ON和OFF状态下均具有10 ms的信号延迟。与其他继电器输出模块相比，1746-OW16 具有更高的背板电流消耗。它在 0V DC 时具有 17.5A 的背板电流消耗，在 0V DC 时具有 18.24A 的背板电流消耗。它在 10V DC 时的最小负载电流为 5 mA。1746-OW16 的最大散热功率为 5.7 W。它还具有每个模块的最大连续电流为 16 A。请注意每个模块的连续电流，以确保每个模块的连续电流受到限制，使模块功率不超过 1440VA。

1746-OW16 易于使用。因此，您可以使用计算机设置该模块。它还具有可拆卸的接线端子，可让您轻松地将任何电缆或跳线连接到模块。请使用滑动闩锁、螺钉、螺纹连接器或本产品随附的其他连接方式固定与模块的外部连接。
